Cisco Catalyst 9300 Series Switches

A secure workplace. Anywhere. Everywhere.

Transform your network for the demands of hybrid work. Build a secure foundation that unlocks automation, simplicity, and insights.

>> Cisco Catalyst 9300 Series Switches Product List, Datasheet and Quote

Power your network for the future

Deliver a more secure, sustainable experience that combines speed and scale with advanced automation and analytics.

Transform your workplace

Get the bandwidth, speed, and scale you need to support your hybrid teams, however they choose to work.

Secure your network from the inside out

Empower your network with built-in encryption, ASAc Firewall on board, and advanced AI/ML for continuous zero-trust security.

Manage your network, your way

Deliver exceptional network experiences with the Cisco Catalyst Center on-premises platform, Meraki cloud-managed dashboard or cloud monitoring for Catalyst.

Build sustainability into your network

Use the network as the foundation for smarter, more sustainable buildings that are energy-efficient and promote the occupants' well-being.

Catalyst 9300X copper models

48-port 10G, multigigabit, 90W PoE

C9300X-48HX. Built for secure Wi-Fi 6/6E high-speed access and beyond, with 90W PoE for Cisco smart building deployments. 48-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit. Based on Cisco UADP 2.0sec ASIC, with 100G hardware-based IPsec.

48-port 10G, multigigabit, data

C9300X-48TX. Built for secure Wi-Fi 6/6E high-speed access and beyond. 48-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit, data only. Based on Cisco UADP 2.0sec ASIC, with 100G hardware-based IPsec.

40-port 5G, 8-port 10G, multigigabit, 90W PoE

C9300X-48HXN. Built for secure Wi-Fi 6/6E high-speed access and beyond, with 90W PoE for Cisco smart building deployments. 40-port 5G/2.5G/1G/100M multigigabit, 8-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit. Based on Cisco UADP 2.0sec ASIC, with 100G hardware-based IPsec.

24-port 10G, multigigabit, 90W PoE

C9300X-24HX. Built for secure Wi-Fi 6/6E high-speed access and beyond, with 90W PoE for Cisco smart building deployments. 24-port 10GBASE-T, 10G/5G/2.5G/1G multigigabit, 1000M/100M. Based on Cisco UADP 2.0sec ASIC, with 100G hardware-based IPsec.

Catalyst 9300X fiber models

24-port 25G fiber

C9300X-24Y. Higher density fiber models for campus access and distribution. 24-port 25G/10G/1G (SFP28). Based on Cisco UADP 2.0sec ASIC, with 100G hardware-based IPsec.

12-port 25G fiber

C9300X-12Y. 25G fiber models for campus access and branch. 12-port 25G/10G/1G (SFP28). Based on Cisco UADP 2.0sec ASIC, with 100G hardware-based IPsec.

Catalyst 9300 high-performance models

48-port 1G, 60W PoE, high performance

C9300-48UB. Built with double buffers, MAC and IP scale, and higher access control list (ACL) scale. 48-port 1G/100M/10M, 60W PoE. Based on Cisco UADP 2.0XL ASIC.

24-port 1G, 60W PoE, high performance

C9300-24UB. Built with double buffers, MAC and IP scale, and higher access control list (ACL) scale. 24-port 1G/100M/10M, 60W PoE. Based on Cisco UADP 2.0XL ASIC.

24-port 5G multigigabit, 60W PoE, high performance

C9300-24UXB. Built with double buffers, MAC and IP scale, and higher access control list (ACL) scale. 24-port 5G/2.5G/1G/100M multigigabit, 60W PoE. Based on Cisco UADP 2.0XL ASIC.

Catalyst 9300 90W PoE models

24-port 1G, 90W PoE

C9300-24H. Optimized for wired and wireless converged access, with 24-port 1G/100M, 90W PoE. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC.

48-port 1G, 90W PoE

C9300-48H. Optimized for wired and wireless converged access, with 48-port 1G/100M, 90W PoE. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC.

Catalyst 9300 60W PoE models

24/48-port 1G, 60W PoE

C9300-24U, C9300-48U. Optimized for wired and wireless converged access, with 24- and 48-port 1G/100M, 60W PoE. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC. Orderable with Meraki cloud-management experience.

24-port 10G, multigigabit, 60W PoE

C9300-24UX. Built for secure Wi-Fi 6/6E high-speed access and beyond. 24-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit, 60W PoE. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC. Orderable with Meraki cloud-management experience.

36-port 2.5G, 12-port 10G, multigigabit, 60W PoE

C9300-48UXM. Built for secure Wi-Fi 6/6E high-speed access. 36-port 2.5G/1G/100M multigigabit, 12-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit, 60W PoE. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC. Orderable with Meraki cloud-management experience.

48-port 5G multigigabit

C9300-48UN. Built for secure Wi-Fi 6/6E high-speed access. 48-port 5G/2.5G/1G/100M multigigabit, 60W PoE. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC. Orderable with Meraki cloud-management experience.

Catalyst 9300 1G models

24/48-port 1G copper, data only

C9300-24T, C9300-48T. 24- and 48-port 1G/100M copper, data only. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC. Orderable with Meraki cloud-management experience.

24/48-port 1G copper, 30W PoE

C9300-24P, C9300-48P. 24- and 48-port 1G/100M copper, 30W PoE. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC. Orderable with Meraki cloud-management experience.

24/48-port 1G SFP

C9300-24S, C9300-48S. 24- and 48-port 1G SFP. 40G, 25G, 10G, 1G fiber and 10G multigigabit copper modular uplink options. Based on Cisco UADP 2.0 ASIC.

Catalyst 9300L models

24/48-port 1G copper, data only

C9300L-24T-xx, C9300L-48T-xx. 24- and 48-port 1G/100M copper, data only. Four 10G (-4X) or 1G (-4G) fixed fiber uplink options. Based on Cisco UADP 2.0 ASIC.

24/48-port 1G copper, 30W PoE

C9300L-24P-xx, C9300L-48P-xx. 24- and 48-port 1G/100M copper, 30W PoE. Four 10G (-4X) or 1G (-4G) fixed fiber uplink options. Based on Cisco UADP 2.0 ASIC.

48-port 1G copper, full 30W PoE

C9300L-48PF-4X, C9300L-48PF-4G. 48-port 1G/100M copper, 30W PoE. Four 10G (-4X) or 1G (-4G) fixed fiber uplink options. Based on Cisco UADP 2.0 ASIC.

24-port 1G copper, 60W PoE, 8-port multigigabit

C9300L-24UXG-4X, C9300L-24UXG-2Q. 24-port 60W PoE, 8-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit, 16-port 1G. Four 10G (-4X) or two 40G (-2Q) fixed fiber uplink options. Based on Cisco UADP 2.0 ASIC.

48-port 1G copper, 60W PoE, 12-port multigigabit

C9300L-48UXG-4X, C9300L-48UXG-2Q. 48-port 60W PoE, 12-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit, 36-port 1G. Four 10G (-4X) or two 40G (-2Q) fixed fiber uplink options. Based on Cisco UADP 2.0 ASIC.

48-port 1G copper, 60W PoE, 8-port multigigabit

C9300L-48UX-4Y. 48-port 60W PoE, 8-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit, 40-port 1G. Two 25G fixed fiber uplinks. Based on Cisco UADP 2.0 ASIC.

Catalyst 9300LM models

48-port 1G copper, data only

C9300LM-48T-4Y. Shallow depth chassis. 48-port 1G/100M copper, data only. Four 25G fixed fiber uplinks. Based on Cisco UADP 2.0 ASIC.

24/48-port 1G copper, 60W PoE

C9300LM-24U-4Y, C9300LM-48U-4Y. Shallow depth chassis. 24- and 48-port 1G/100M copper, 60W PoE. Four 25G fixed fiber uplinks. Based on Cisco UADP 2.0 ASIC.

48-port 1G copper, 60W PoE, 8-port 10G, multigigabit

C9300LM-48UX-4Y. Shallow depth chassis. 48-port 60W PoE, 8-port 10GBASE-T, 10G/5G/2.5G/1G/100M multigigabit, 40-port 1G. Four 25G fixed fiber uplinks. Based on Cisco UADP 2.0 ASIC.

When simplicity and functionality meet

Experience the simplicity and freedom of managing your network from anywhere using the intuitive Meraki cloud-managed dashboard. Unleash operational efficiency from day 0 with the new Meraki dashboard managed Catalyst 9300 models, or achieve the perfect balance between operational effectiveness and powerful control with Cloud Monitoring for Catalyst.
