Detail: | Cisco ASA 5500 Edition Bundle ASA5512-K9 ASA 5512-X with SW, 6GE Data, 1GE Mgmt, AC, 3DES/AES |
Model: | AASA5512-K9 |
Condition: | New |
Related: | ASA5515-K9 Cisco ASA 5500 Edition Bundle Firewalls ASA5525-K9 Cisco 8GE Edition Bundle Security Appliance ASA5512-IPS-K9 ASA 5512-X 6GE Port data Cisco Firewalls ASA5512-FPWR-K9 FirePOWER 6GE Port data Cisco Firewalls |
Warranty: |
1 Year-Warranty
100% Money-back
Free After-Sales Service
|
Shipping: |
Air Shipping to
United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the estimated delivery time. |
Ships to:
10.5
|
2-7 Days
US$
|
Payment: |
More
|
(Note: Cisco discount and Stock always changed, we will try most effort to follow it but can not ensure every web was changed accordingly. So Our Products Service will contact you after order if meet such special condition.)
Cisco ASA 5512-K9 delivers superior performance with up to 1 Gbps stateful inspection throughput, 250 IPsec VPN peers, 100,000 concurrent connections and 1 expansion slot makes it ideally suited for the small, mid-size enterprises or branch offices while delivering enterprise-strength security. ASA 5512-K9 needs Security PLus license to support Active/Active and Active/Standby.
Product Code | ASA5512-K9 |
Interfaces | 6 copper GE ports, 1 copper GE management port, 1 expansion slot |
Stateful inspection throughput (maximum) | 1 Gbps |
3DES/AES VPN throughput | 200 Mbps |
IPsec VPN peers | 250 |
Virtual interfaces (VLANs) | 50; 100 |
Memory | 4 GB |
Flash | 4 GB |
Height (rack units) | 1 RU |
Dimensions (D x H x W) | 4.24 x 42.9 x 39.5 cm |
Package Weight | 13.1 Kg |
Note:
(1) | Management 0/0 interface | (4) | Rear panel LEDs |
(2) | Console port | (5) | USB ports |
(3) | GigabitEthernet data interfaces | (6) | Power supply |
Licenses | Description |
L-ASA-AC-E-5512= | AnyConnect Essentials VPN Licenses - Cisco L-ASA-AC-E-5512=, AnyConnect Essentials VPN License - ASA 5515-X (250 Users) for Cisco ASA 5500 Series |
L-ASA-AC-M-5512= | Cisco VPN Licenses - L-ASA-AC-M-5512= AnyConnect Mobile - ASA 5515-X (req. Essentials or Premium) VPN Licenses for Cisco |
L-ASA5512-ME-K9= | Cisco ASA 5500 Series Unified Communications Licenses - L-ASA5512-ME-K9, ASA 5512-X Intercompany Media Engine K9 License (eDelivery) for Cisco ASA 5500 Series |
L-ASA5512-IPS-SSP= | Cisco ASA 5500 Series IPS Security Services Processors - L-ASA5512-IPS-SSP=, ASA 5512-X IPS SSP License for Cisco ASA 5500 Series |
L-ASA-VPNP-5512= | Cisco VPN Licenses - L-ASA-VPNP-5512 Premium Shared VPN Participant License - ASA 5512-X VPN Licenses for Cisco |
L-ASA-AC-PH-5512= | Cisco VPN Licenses - L-ASA-AC-PH-5512= AnyConnect VPN Phone License - ASA 5512-X (req Premium lic) VPN Licenses for Cisco |
Models | ASA5512-K9 | ||
Stateful Inspection Throughput (maximum) | 1 Gbps | 1.2 Gbps | 2 Gbps |
Next-generation firewall throughput (multiprotocol) | 200 Mbps | 350 Mbps | 650 Mbps |
Memory | 4GB | 8GB | 8GB |
Flash | 4GB | 8GB | 8GB |
Height (rack units) | Desk Top | 1 RU | 1 RU |
Do you have any question about the ASA5512-K9?
Contact us now via [email protected].
ASA5512-K9 Specifications | |
Feature | Cisco ASA 5512-X; Security Plus |
Stateful Inspection Throughput (Maximum) | 1 Gbps |
Stateful Inspection Throughput (Multiprotocol) | 500 Mbps |
IPS Throughput | 250 Mbps (Extra hardware not required) |
Next-Generation Throughput (Multiprotocol) | 200 Mbps |
3DES/AES VPN Throughput | 200 Mbps |
Users/Nodes | Unlimited |
IPsec VPN Peers | 250 |
Cisco Cloud Web Security Users | 100 |
Premium AnyConnect VPN Peers (Included/Maximum) | 2/250 |
Concurrent Connections | 100,000 |
New Connections/Second | 10,000 |
Virtual Interfaces (VLANs) | 50; 100 |
Security Contexts (Included/Maximum) | 0,0; 2,5 |
High Availability | Not supported; Active/Active and Active/Standby |
Expansion Slot | 1 interface card |
User-Accessible Flash Slot | No |
USB 2.0 Ports | 2 |
Integrated I/O | 6 GE Copper |
Expansion I/O | 6 GE Copper or 6 GE SFP |
Serial Ports | 1 RJ-45 console |
Solid State Drive | 1 slot, 120 GB MLC SED |
Memory | 4 GB |
Minimum System Flash | 4 GB |
System Bus | Multibus architecture |
Temperature | 23 to 104°F (-5 to 40°C) |
Relative Humidity | 10 to 90 percent noncondensing |
Altitude | Designed and tested for 0 to 15,000 ft (4572m) |
Shock | 70G, 4.22 m/sec |
Vibration | 0.41 Grms2 (3 to 500 Hz) random input |
Acoustic Noise | 64.2 dBa max |
Temperature | -13 to 158ºF (-25 to 70ºC) |
Relative Humidity | 10 to 90 percent noncondensing |
Altitude | Designed and tested for 0 to 15,000 ft (4570m) |
Shock | 70G, 4.22 m/sec |
Vibration | 1.12 Grms2 (3 to 500 Hz) random input |
AC Range Line Voltage | 100 to 240 VAC |
AC Normal Line Voltage | 100 to 240 VAC |
AC Current | 4.85A |
AC Frequency | 50/60 Hz |
Dual-Power Supplies | None |
DC Domestic Line Voltage | -40.5 to 56 VDC (-48 VDC nominal) |
DC International Line Voltage | -55 to -72 VDC (-60 VDC nominal) |
DC Current | 15A (maximum input) |
Steady State | 51W |
Maximum Peak | 56W |
Maximum Heat Dissipation | 192 BTU/hr |
Form Factor | 1 RU, 19-in. rack-mountable |
Dimensions (H x W x D) | 1.67 x 16.7 x 15.6 In (4.24 x 42.9 x 39.5 cm) |
Weight (with AC Power Supply) | 13.39 lb (6.07 kg) |
Safety | IEC 60950-1: 2005, 2nd <Edition EN 60950-1:2006+A11: 2009 UL 60950-1:2007, 2nd Edition; CSA C22.2 No. 60950-1-07, 2nd> Edition |
Electromagnetic Compatibility (EMC) | CE: EN55022 2006+A1: 2007 Class A; EN55024 1998+A1:2001+A2:2003; EN61000-3-2 2009; EN61000- 3-3 2008; FCC: CFR 47, Part 15 Subpart B Class A 2010, ANSI C63.4 2009; ICES-003 ISSUE 4 FEBRUARY.2004; VCCI: V-3/2011.04; C-TICK: AS/NZS CISPR 22,2009 KC: KN22 & KN24 |
Industry Certifications | In process |
What is Guaranteed.
After receiving your order, take a full month to try it out. If you find quality is not good , we'll take it back and refund your money. Your complete satisfaction is GUARANTEED or your money back. That's guaranteed.
After your order items which are available. We will use most fast delivery way to global countries. Normally we will ship out cargos during 3 -5 days. And international delivery will take about 3- 10 days according to your location.
Service Never Ends.
Hardwares Warrany Time:
Original New Sealed Hardware: 3 Years
Refurbished/Used Original Devices: 1 Year
After warranty time, you also can contact us to return back for repair service. Everything you purchase from HI-NETWORK.COM. We will offer lifetime online service support for your any possible questions.
