CPAK-100G-LR4
  • CPAK-100G-LR4

OEM Cisco CPAK-100G-LR4 Compatible 1310nm 10km DOM Duplex LC SMF Optical Transceiver Module

484 $968 (50% OFF)
4.7
4.7/5.0
Q/A
15 Sold/Mon
Detail: CPAK-100G-LR4= Transceiver module, 10km SMF
Model: CPAK-100G-LR4
Condition: Compatible Cisco OEM; In stock
Related:
Warranty:
3 Years-Warranty
100% Money-back
Free After-Sales Service
Shipping:
Air Shipping to United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
Ships to:
0.2
2-7 Days US$
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Quantity
- +
add to Cart quick quote
add to Cart quick quote
  • Description
  • Specification
  • Reviews
  • Q&A
  • Warranty
  • Download

OEM Cisco CPAK-100G-LR4 Compatible 1310nm 10km DOM Duplex LC SMF Optical Transceiver Module


(Note: Cisco discount and Stock always changed, we will try most effort to follow it but can not ensure every web was changed accordingly. So Our Products Service will contact you after order if meet such special condition.)


Cisco CPAK® 100GBASE fiber modules for Cisco® switches and routers offer a selection of high-density 100-Gbps connectivity solutions. The modules are especially well suited for connections in enterprise and service provider data centers and in service provider edge networks.


Quick Specification


Product Code

CPAK-100G-LR4=

Description

100GBASE-LR4 Cisco CPAK Module for SMF (terminated with LC Connectors)

Dimensions

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

Wavelength (nm)

1310

Cable Type

SMF Duplex

Core Size (Microns)

9-micron core SMF per G.652

Modal Bandwidth (MHz*km)

\

Cable Distance

10 km


The Front Panel:

cpak-100g-lr4=-blue-datasheet



The Accessories for CPAK-100G-LR4

Cisco CPAK 100GBASE module features and benefits:


Requirement

Cisco CPAK Module Supporting Feature

Accommodate ever-growing bandwidth requirements

Up to 10 100-Gigabit Ethernet connections deliver as much as 1 Tbps of front-panel bandwidth

Control costs

Form factor consumes 40% less power than CFP2 and 70% less power than CFP form factors

Real estate conservation

Minimal footprint allows 20% greater port density and bandwidth than competing products

High availability for business continuity

Hot-swappable input/output device plugs into a Cisco CPAK-module-based switch, router, or optical platform port

Accommodate a variety of distance and fiber type requirements

Flexible interface choices

Investment protection, affordable migration to higher bandwidth

•Support for a “pay-as-you-grow” model

•Can plug any Cisco 100-Gbps, 40-Gbps, and 10-Gbps line cards into Cisco CPAK modules (supports the Cisco AnyPort solution)

Manage performance

Digital Optical Monitoring (DOM) support

Proper functioning and high performance with all Cisco platforms

Cisco quality identification (ID) feature enables a Cisco platform to identify whether the module is certified and tested by Cisco

Standards compliance for equipment flexibility and choice

Interoperability with any IEEE-compliant: 100GBASE-SR4, 100GBASE-LR4, 100GBASE-SR10, 40GBASE-SR4, 10GBASE-SR, 10GBASE-LR


Platform Support:


Cisco CPAK 100GBASE modules are supported on Cisco high-end switches, routers, and transport equipment:
● ASR 9000 Series Router
● CRS-X Carrier Routing System
● NCS 2000, 4000, and 6000 Series Routers
● Nexus 7000 and 7700 Series Switches
● Cisco ONS Transport PlatformCompare to Similar Items



Compare to Similar Items


Parameters

CPAK-100G-CWDM4=

CPAK-100GE-LR4=

CPAK-100G-ER4L=

CPAK-100G-LR4=

CPAK-100G-PSM4=

CPAK-100G-SR4=

CPAK-100G-SR10=

Description

100GBASE-CWDM4 Cisco CPAK Module for SMF

100GBASE-LR4 Cisco CPAK Module for SMF (terminated with LC Connectors)

100GBASE-ER4 Lite Cisco CPAK Module for SMF

100GBASE-LR4 Cisco CPAK Module for SMF (terminated with LC Connectors)

100GBASE PSM4 Cisco CPAK Module for SMF

100GBASE-SR4 Cisco CPAK Module for MMF

100GBASE-SR10 Cisco CPAK Module for MMF

Dimensions

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

Wavelength (nm)

1271, 1291, 1311, 1331

1310

1310

1310

1295 to 1325

850

850

Cable Type

SMF Duplex

SMF Duplex

SMF Duplex

SMF Duplex

SMF (12 fibers)

MMF (12 fibers)

MMF (12 fibers)

Core Size (Microns)

9-micron core SMF per G.652

9-micron core SMF per G.652

9-micron core SMF per G.652

9-micron core SMF per G.652

9-micron core SMF per G.652

50.0

50.0

50.0

50.0

Modal Bandwidth (MHz*km)

\

\

\

\

\

2000 (OM3)

4700 (OM4)

2000 (OM3)

4700 (OM4)

Cable Distance

2 km

10 km

25 km

10 km

500 m

70 m

100 m

100 m

150 m

Supported Mode

1x100G

1x100G

1x100G

1x100G

1x100G

1x100G

1x100G

2x40G

10x10G

Supported Protocol

IEEE 802.3ba

IEEE 802.3ba

IEEE 802.3ba

ITU OTU4

IEEE 802.3ba

ITU OTU4

IEEE 802.3ba

IEEE 802.3ba

1x100G:

IEEE 802.3ba

ITU OTU4

2x40G:

IEEE 802.3ba

ITU OTU3

10x10G:

IEEE 802.3ae

FC

ITU OTU2

ITU OTU1e

ITU OTU2e


Get More Information


Do you have any question about the CPAK-100G-LR4?

Contact us now via   [email protected]

Specific Data Sheet:


Description

100GBASE-LR4 Cisco CPAK Module for SMF (terminated with LC Connectors)

Dimensions

11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

Cisco CPAK port cabling specifications

Wavelength (nm)

1310

Cable Type

SMF Duplex

Core Size (Microns)

9-micron core SMF per G.652

Modal Bandwidth (MHz*km)

\

Cable Distance

10 km

Optical transmit and receive specifications

Type

100GBASE-LR4 1310 nm SMF

Transmit Power

Max:+4.5 per lane

Min:-4.3 per lane

Receive Power (dBm)

Max:+4.5 per lane

Min:-10.6 per lane

Transmit and Receive Center Wavelength Range (nm)

Four lanes:

1294.53 to 1296.59

1299.02 to 1301.09

1303.54 to 1305.63

1308.09 to 1310.19

Supported Mode

1x100G

Supported Protocols

IEEE 802.3ba

ITU OTU4

Environmental conditions and power requirements

Storage temperature

-40 to 85° C (-40 to 185° F)

Operating temperature

0 to 70° C (32 to 158° F)

Power consumption

At 70° C: <8.0 W maximum
