Enclosure  type

Rack-mountable  - 1U

Ports

48 x 10/100/1000 + 4 x 1G SFP

Network management Interface

10/100 Mbps Ethernet (RJ-45)

Available PoE Power

None

Forwarding  bandwidth(Gbps)

108Gbps

Maximum stacking number

8

Stack Bandwidth

80G

Forwarding Performance

107.1Mpps

Switching bandwidth

216Gbps

Maximum active VLANs

1023

MAC Address Table Size

16K (default)

CPU

APM86392 600MHz dual core

RAM

512 MB

Flash Memory

128 MB

Status Indicators

Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, and link speed

Expansion / Connectivity

Console ports

USB (Type-B), Ethernet (RJ-45)

Stacking cable

Optional

Power Redundancy

Option (PWR-RPS2300)

Voltage range (Auto)

110V-240V

Power Consumption Operational

0.051KVA

Miscellaneous

Width

17.5 Inches (44.5 cm)

Depth

11 Inches (27.9 Cm)

Height

1.75 Inches (4.5 cm)

Package Weight

20.26 Pounds (9.19Kg)

Weight

9.4 Pounds (4.2Kg)

Rack Mounting Kit

optional

MTBF in hours

476,560

Compliant Standards

IEEE 802.1D Spanning Tree Protocol

IEEE 802.1p CoS Prioritization

IEEE 802.1Q VLAN

IEEE 802.1s

IEEE 802.1w

IEEE 802.1X

IEEE 802.1ab (LLDP)

IEEE 802.3ad

IEEE 802.3af and IEEE 802.3at

IEEE 802.3ah (100BASE-X single/multimode fiber only)

IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T  ports

IEEE 802.1D Spanning Tree Protocol

IEEE 802.1p CoS Prioritization

IEEE 802.1Q VLAN

IEEE 802.1s

IEEE 802.1w

IEEE 802.1X

IEEE 802.1ab (LLDP)

IEEE 802.3ad

IEEE 802.3af and IEEE 802.3at

IEEE 802.3ah (100BASE-X single/multimode fiber only)

IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T  ports

System software / license

System software

IOS LAN BASE

license

NERGY-MGT-100-K9, EW-DO-100-DE

features

Jumbo Frames

VLANS

Voice Vlan

VTPv2

CDPv2

LLDP

802.3ad LACP

PVST/PVST+

802.1W/802.1S

Port Fast/Uplink Fast

port CoS Trust and Override

Scheduling

Priority Queuing

Configure CoS Priority Queues

Weighted Tail Drop

DSCP transparency

Network security

SSH, SSL and SCP

RADIUS and TACACS+

SNMPv3 crypto

802.1x

802.1x Accounting / MIB

802.1x w/ portsecurity

802.1x w/Voice VLAN

802.1x Guest VLAN

802.1x VLAN assignment

802.1x MAC-Auth Bypass

BPDU/Root Guard

Port Security

Private VALN Edge

Storm Control

Block unknown unicast andmulticast

IGMP Snooping

IGMP Filter/Throttle

Environmental Ranges

Operating temperature up to 5000 ft (1500 m)

23ºF to 113ºF

Operating temperature up to 10,000 ft (3000 m)

23ºF to 104ºF

Short-term exception at sea level*

23ºF to 131ºF

Short-term exception up to 5000 feet (1500 m)*

23ºF to 122ºF

Short-term exception up to 10,000 feet (3000 m)*

23ºF to 113ºF

Short-term exception up to 13,000 feet (4000 m)*

23º to 104ºF

Storage temperature up to 15,000 feet (4573 m)

-13º  to 158ºF

Operating altitude

Up to 10,000 feet

Storage altitude

Up to 13,000 feet

Operating relative humidity

10% to 95% noncondensing

Storage relative humidity

10% to 95% noncondensing
