Processor Type Intel
Processor family Intel® Xeon® Scalable 8100/8200 series - Intel® Xeon® Scalable 3100/3200 series
Processor core available 4 to 28 core, depending on model
Processor cache 8.25 - 38.50 MB L3, depending on processor
Maximum memory 3.0 TB with 128 GB DDR4; 6.0 TB with HPE 512GB 2666 Persistent Memory Kit
Memory Slots 24 DIMM slots
Memory type HPE DDR4 SmartMemory and Intel® Optane™ persistent memory 100 series for HPE, depending on model
NVDIMM type HPE NVDIMM-N *Only available on 1st Generation Intel® Xeon® Scalable Processors
NVDIMM rank Single rank
NVDIMM capacity 16 GB
Drive supported 4 LFF SAS/SATA, 8 SFF SAS/SATA + 2 NVMe, 10 SFF SAS/SATA, 10 SFF NVMe, 1 SFF or 1 Dual UFF rear drive optional depending on model
Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses)
System fan features Hot-plug redundant standard
Expansion Slots3, for detailed descriptions refer to the QuickSpecs
Network Controller Embedded 4 X 1GbE Ethernet Adapter (select models) or HPE FlexibleLOM and optional PCIe stand-up cards, depending on model
Storage controller HPE Smart Array S100i and/or HPE Essential or Performance RAID controllers, depending on model
Warranty 3 YEARS
Processor number 1 or 2
Processor speed 3.9 GHz, maximum depending on processor
Memory, standard 3.0 TB (24 X 128 GB) LRDIMM; 6.0 TB (12 X 512 GB) HPE Persistent Memory
Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
Form Factor1U
Weight 28.74 lb minimum, 37 lb maximum
Weight 13.04 kg minimum, 16.78 kg maximum
Minimum dimensions ( H x W x D)SFF Chassis: 1.69 x 17.11 x 27.83 in, LFF Chassis: 1.69 x 17.11 x 29.5 in
Minimum dimensions ( H x W x D)SFF Chassis: 4.29 x 43.46 x 70.7 cm, LFF Chassis: 4.29 x 43.46 x 74.98 cm
