Model

S6720-30C-EI-24S-AC

Part Number

02350DMN

Description

S6720-30C-EI-24S Bundle (24 10 Gig SFP+,2 40 Gig QSFP+ interface, with 1 interface slot, with 600W AC power supply)

Dimensions without packaging (H x W x D) [mm(in.)]

Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 424.7 mm (1.75 in. x 17.40 in. x 16.72 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 44.4 mm x 442.0 mm x 451.8 mm (1.75 in. x 17.40 in. x 17.79 in.)

Dimensions with packaging (H x W x D) [mm(in.)]

175.0 mm x 710.0 mm x 550.0 mm (6.89 in. x 27.95 in. x 21.65 in.)

Chassis height [U]

1

Chassis material

Metal

Weight with packaging [kg(lb)]

9.8

Typical power consumption [W]

147

Typical heat dissipation [BTU/hour]

501.58

Maximum power consumption [W]

233.7

Maximum heat dissipation [BTU/hour]

797.41

Static power consumption [W]

-

MTBF [years]

80.6

MTTR [hours]

2

Availability

> 0.99999

Noise at normal temperature (acoustic power) [dB(A)]

72.1

Noise at normal temperature (acoustic pressure) [dB(A)]

59.3

Number of card slots

1

Number of power slots

2

Number of fans modules

1

Redundant power supply

1+1

Pluggable AC and DC power modules can be used together in the same switch.

Long-term operating temperature [°C(°F)]

0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)

Restriction on the operating temperature variation rate [°C(°F)]

When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Storage temperature [°C(°F)]

-40°C to +70°C (-40°F to +158°F)

Long-term operating relative humidity [RH]

5% to 95%, noncondensing

Long-term operating altitude [m(ft.)]

0-5000 m (0-16404 ft.)

Storage altitude [m(ft.)]

0-5000 m (0-16404 ft.)

Power supply mode

Pluggable power supply

Rated input voltage [V]

- AC input: 100 V AC to 240 V AC; 50/60 Hz

- DC input: –48 V DC to –60 V DC

Input voltage range [V]

- AC input: 90 V AC to 264 V AC; 47 Hz to 63 Hz

- DC input: -38.4 V DC to -72 V DC

Maximum input current [A]

The current specifications depend on the pluggable power modules in use. For details, see the related power module specifications.

Memory

2 GB

Flash memory

512 MB in total. To view the available flash memory size, run the display version command.

Console port

RJ45

Eth Management port

RJ45

USB

Supported

RTC

Supported

RPS input

Not supported

Service port surge protection [kV]

-

Power supply surge protection [kV]

±6 kV in differential mode, ±6 kV in common mode

Ingress protection level (dustproof/waterproof)

IP20

Types of fans

Pluggable

Heat dissipation mode

Heat dissipation with fan, intelligent fan speed adjustment

Airflow direction

Air intake from left, front and right, air exhaustion from behind

PoE

Not supported

Certification

EMC certification

Safety certification

Manufacturing certification
