Part Number

98010794

Memory (RAM)

512 MB

Flash

512 MB in total. To view the available flash memory size, run the display version command.

Mean time between failures (MTBF)

67.89 years

Mean time to repair (MTTR)

2 hours

Availability

> 0.99999

Service port surge protection

±1.5 kV in differential mode, ±6 kV in common mode

Power supply surge protection

±6 kV in differential mode, ±6 kV in common mode

Dimensions (H x W x D)

Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 250.0 mm x 180.0 mm (1.72 in. x 9.8 in. x 7.1 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 250.0 mm x 186.36 mm (1.72 in. x 9.8 in. x 7.34 in.)

Weight (with packaging)

2.65 kg (5.84 lb)

Stack ports

Eight 10/100/1000BASE-T ports and four 10G SFP+ ports

RTC

Not supported

RPS

Not supported

PoE

Not supported

Rated voltage range

100 V AC to 240 V AC, 50/60 Hz

110 V DC to 250 V DC

Maximum voltage range

90 V AC to 264 V AC, 47 Hz to 63 Hz

110 V DC to 250 V DC

Maximum power consumption (100% throughput, full speed of fans)

17 W

Typical power consumption (30% of traffic load)

·         Tested according to ATIS standard

·         EEE enabled

·         No PoE power consumption

15.6 W

Operating temperature

-40°C to +65°C (-40°F to +149°F) (installed in the sealing cabinet)

-40°C to +70°C (-40°F to +158°F) (installed in the ventilation cabinet, with the wind speed of at least 40 LFM)

-40°C to +75°C (-40°F to +167°F) (installed in the ventilation cabinet shipped with fans with a fan speed of at least 200 LFM)

Storage temperature

-40°C to +85°C (-40°F to +185°F)

IP rating

IP30

Noise under normal temperature (27°C, sound power)

Noise-free (no fans)

Relative humidity

5% to 95%, noncondensing

Operating altitude

0-5000 m (0-16404 ft.)

Certification

EMC certification

Safety certification

Manufacturing certification
