Detail: | S2720-52TP-PWR-EI(32 Ethernet 10/100 ports,16 Ethernet 10/100/1000 ports,4 Gig SFP,PoE+,370W PoE AC 110/220V) |
Model: | S2720-52TP-PWR-EI (98010675) |
Condition: | Factory Sealed New |
Related: | Huawei Switch S2720-52TP-EI (98010673) Huawei Switch S2720-12TP-PWR-EI (98010734) Huawei Switch S2720-28TP-PWR-EI (98010678) Huawei Switch S2720-28TP-PWR-EI-L (98010677) |
Warranty: |
3 Years-Warranty
100% Money-back
Free After-Sales Service
|
Shipping: |
Air Shipping to
United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the estimated delivery time. |
Ships to:
9.0
|
2-7 Days
US$
|
Payment: |
More
|
The S2720-EI is a next-generation access switch that provides flexible 100M, GE access ports and GE uplink ports. Building on next-generation, high-performance hardware and the Huawei Versatile Routing Platform (VRP), the S2720-EI supports intelligent Stack (iStack), flexible Ethernet networking, and diversified security control. It provides customers with a green, easy-to-manage, easy-to-expand, and cost-effective 100M to the desktop solution.
Model | S2720-52TP-PWR-EI |
Part Number | 98010675 |
Memory (RAM) | 512 MB |
Flash | 512 MB in total. To view the available flash memory size, run the display version command. |
PoE | Supported |
Dimensions (H x W x D) | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 314.8 mm (1.72 in. x 17.4 in. x 12.39 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 323.8 mm (1.72 in. x 17.4 in. x 12.75 in.) |
Weight (including package) | 5.9 kg (13.01 lb) |
① | Thirty-two PoE+ 10/100BASE-TX ports |
② | Sixteen PoE+ 10/100/1000BASE-T ports |
③ | Four 1000BASE-X ports |
④ | PNP button |
⑤ | One console port |
⑥ | Ground screw |
⑦ | Jack reserved for AC power cable locking strap |
⑧ | AC socket |
Models | |||
Switching Capacity | 68 Gbit/s | 68 Gbit/s | 336 Gbit/s |
Forwarding Performance | 12.6 Mpps | 20.4 Mpps | 34.8 Mpps |
Fixed Ports | Downlink: 4 x 10/100 Base-TX Ethernet ports; 4 x GE ports Uplink: 4 x GE ports | Downlink: 16 x 10/100 Base-TX Ethernet ports; 8 x GE ports Uplink: 4 x GE ports | Downlink: 32 x 10/100 Base-TX Ethernet ports; 16 x GE ports Uplink: 4 x GE ports |
MAC Address Table | 16K MAC address entries Configurable aging time of MAC addresses Blackhole MAC address entries Limit on the number of MAC addresses learned on a port | ||
VLAN Features | 4K VLANs VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and interfaces Port-based QinQ | ||
IP Routing | Static routing RIP, RIPng, and OSPF | ||
Interoperability | VLAN-based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST) Link-type Negotiation Protocol (LNP) (similar to DTP) VLAN Central Management Protocol (VCMP) (similar to VTP) |
Do you have any question about the S2720-52TP-PWR-EI 98010675?
Contact us now via[email protected]
Part Number | 98010675 |
Model | S2720-52TP-PWR-EI |
Memory (RAM) | 512 MB |
Flash | 512 MB in total. To view the available flash memory size, run the display version command. |
Mean time between failures (MTBF) | 38 years |
Mean time to repair (MTTR) | 2 hours |
Availability | > 0.99999 |
Service port surge protection | Common mode: ±7 kV |
Power supply surge protection | ±6 kV in differential mode, ± 6 kV in common mode |
Dimensions (H x W x D) | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 314.8 mm (1.72 in. x 17.4 in. x 12.39 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 323.8 mm (1.72 in. x 17.4 in. x 12.75 in.) |
Weight (including package) | 5.9 kg (13.01 lb) |
Stack ports | Four 1000BASE-X ports |
RTC | Not supported |
RPS | Not supported |
PoE | Supported |
Rated voltage range | 100 V AC to 240 V AC, 50/60 Hz |
Maximum voltage range | 90 V AC to 264 V AC, 47 Hz to 63 Hz |
Maximum power consumption (100% throughput) | Not providing the PoE function: 53.7 W 100% PoE loads: 435 W (system power consumption: 65.4 W, PoE: 369.6 W) |
Typical power consumption (30% of traffic load) · Tested according to ATIS standard · EEE enabled · No PoE power consumption | 42.5 W |
Operating temperature | 0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) |
Short-term operating temperature | -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.) |
Storage temperature | -40°C to +70°C (-40°F to +158°F) |
Noise under normal temperature (27°C, sound power) | < 48.3 dB(A) |
Relative humidity | 5% to 95%, noncondensing |
Operating altitude | 0-5000 m (0-16404 ft.) |
Certification | EMC certification Safety certification Manufacturing certification |
