Model

S1730S-S24T4X-A

First supported version

V200R019C10

Description

S1730S-S24T4X-A (24*10/100/1000BASE-T ports, 4*10GE SFP+ ports, AC power)

Wide [mm]

442.0 mm

Depth [mm]

220.0 mm

Height [mm]

43.6 mm

Chassis height [U]

1

Weight with packaging [kg(lb)]

4

Typical power consumption [W]

27

Maximum power consumption [W]

43

Typical heat dissipation [BTU/hour]

92.13

Maximum heat dissipation [BTU/hour]

146.7

Heat dissipation mode

Heat dissipation with fan, intelligent fan speed adjustment

Power supply mode

AC built-in

Rated input voltage [V]

- AC input: 100 V AC to 240 V AC, 50/60 Hz

- High-Voltage DC input: 240 V DC

Input voltage range [V]

- AC input: 90 V AC to 264 V AC, 47 Hz to 63 Hz

- High-Voltage DC input: 190 V DC to 290 V DC

Maximum input current [A]

2 A

Number of card slots

0

Number of power slots

0

Memory

1 GB

Flash memory

512 MB in total. To view the available flash memory size, run the display version command.

Redundant power supply

Not supported

Types of fans

Built-in

Noise at normal temperature (acoustic pressure) [dB(A)]

32.5

Noise at normal temperature (acoustic power) [dB(A)]

47.3

Airflow direction

Air intake from left and front, air exhaustion from right

Long-term operating temperature [°C(°F)]

-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.)

Short-term operating temperature [°C(°F)]

-5°C to +55°C (23°F to 131°F) at an altitude of 0-1800 m (0-5906 ft.)

Storage temperature [°C(°F)]

-40°C to +70°C (-40°F to +158°F)

Restriction on the operating temperature variation rate

When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

The equipment can operate beyond the normal operating temperature range for a short-term period, but the following conditions must be met:

- The equipment operates at a temperature of over 50°C (122°F) consecutively for at most 96 hours in one year.

- The equipment operates at a temperature of over 50°C (122°F) for a total of no more than 360 hours in one year.

- The equipment operates at a temperature of over 50°C (122°F) for no more in 15 times in one year.

The equipment may be damaged or experience unexpected exceptions if any of the preceding limits is exceeded.

The equipment cannot start when the temperature is lower than 0°C (32°F). The maximum distance of optical modules used in these conditions cannot exceed 10 km.

Long-term operating relative humidity [RH]

5% to 95%, noncondensing

Long-term operating altitude [m(ft.)]

0-5000 m (0-16404 ft.)

Storage altitude [m(ft.)]

0-5000 m (0-16404 ft.)

MTBF [year]

50.68

MTTR [hour]

2

Availability

>0.99999

1000M electrical interface

24

10GE optical interface

4

USB

Supported

Console port

RJ45

Eth Management port

RJ45

Service port surge protection

Common mode: ±7 kV

Power supply surge protection

±6 kV in differential mode, ±6 kV in common mode

RPS input

Not supported

PoE

Not supported
