Model

S1728GWR-4P

Part number

98010435

Description

S1728GWR Mainframe (24 x 10/100/1000Base-T and 4 x 1000 BASE-X SFP ports)

Dimensions (H x W x D)

43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.)

Weight (including packaging)

< 3 kg (6.62 lb)

Memory (RAM)

128 MB

Flash

32 MB

Mean time between failures (MTBF)

24.65 years

Mean time to repair (MTTR)

2 hours

Availability

> 0.99999

Stack ports

Not supported

RTC

Not supported

RPS

Not supported

PoE

Not supported

Rated voltage range

100 V AC to 240 V AC, 50/60 Hz

Maximum voltage range

90 V AC to 264 V AC, 47 Hz to 63 Hz

Maximum power consumption (100% throughput)

15 W

Operating temperature

0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)

NOTE:

When the altitude is 1800-2000 m (5906-6562 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Noise under normal temperature (27°C, sound power)

Noise-free (no fans)

Relative humidity

5% to 95%, noncondensing

Operating altitude

0-2000 m (0-6562 ft.)

Certification

EMC certification

Safety certification

Manufacturing certification
