| Detail: | AR2240 Integrated Chassis Components |
| Model: | AR2240 (02358546) |
| Condition: | Factory Sealed New |
| Related: | |
| Warranty: |
3 Years-Warranty
100% Money-back
Free After-Sales Service
|
| Shipping: |
Air Shipping to
United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the estimated delivery time. |
| Ships to:
9.0
|
2-7 Days
US$
|
| Payment: |
More
|
Huawei AR G3 AR200 Series router AR208E fixed interface access enterprise router AR0M008EBA00 provides routing and switching functionality for small business or branch offices. Huawei AR G3 AR0M008EBA00 equips 1 G.SHDSL 8-wired WAN port, 8 Fast Ethernet 10/100 LAN ports,1 USB and provides total 150Mbps system capacity. Dual-core processor separate data and control planes to ensure the high performance. Robust security feature include build-in, comprehensive authentication, defense mechanisms and a broad range of VPN options.
Model | AR2240 |
Part Number | 02358546 |
Memory | Configured with SRU40/SRU60/SRU80/SRU100: 2 GB Configured with SRU200: 4 GB |
Flash | 16 MB |
Service interfaces (standard configuration) | WAN interfaces: Configured with SRU40/SRU60/SRU80/SRU100: 1 GE electrical interface and 2 GE combo interfaces Configured with SRU200: 2 10 GE optical interfaces and 4 GE combo interfaces LAN interfaces: none |
Extended slots | 4 SIC slots, 2 WSIC slots, and 2 XSIC slots |
Power module type | Pluggable power module |
Weight | 8.85 kg (19.51 lb) |
Dimensions (W x D x H) | 442.0 mm x 470.0 mm x 88.1 mm |
① | SRU slots |
② | Two power module slots |
③ | Fan module slot |
④ | Ground point |
⑤ | ESD jack |
⑥ | Product model silkscreen |
⑦ | Four SIC slots |
⑧ | Two WSIC slots |
⑨ | Two XSIC slots |
Module | Description |
AC power module | |
AR0MPSAP3500 | 350W AC Power Module |
DC power module | |
AR0MPSDP3500 | 350W DC Power Module |
WAN interface card | |
AR-1E3T3M-W | 1-Port Channelized/Unchannelized E3/T3 WAN Interface Card |
AR0MSDE11A00 | 1-Port Fractional Channelized E1/T1 WAN Interface Card |
xDSL interface card | |
AR01SLV1XA | 1-Port VDSL2 over POTS WAN Interface Module |
AR0MSLA1XA01 | 1-Port ADSL2+ ANNEX A/M WAN Interface Module |
Model | AR2240 | AR2220E |
WAN Speed with Services | 1 Gbit/s (with SRU40) 2 Gbit/s (with SRU80) 1 Gbit/s (with SRU100E) 4.5 Gbit/s (with SRU200) | 800 Mbit/s |
Fixed WAN Ports | SRU40: 3 x GE (2 x Combo) SRU80: 3 x GE (2 x Combo) SRU100E: 4 x GE Combo+ 2 x GE SFP SRU200: 4 x GE Combo+ 2 x 10 GE SFP+ | 2 x GE |
Wireless Controller | Wireless Controller is integrated in software | |
Memory | 2 GB/4 GB | 1 GB |
Do you have any question about the AR2240 02358546?
Contact us now viainfo@hi-network.
Part Number | 02358546 |
Model | AR2240 |
First Supported Version | V200R001C00 |
WAN Speed with Services*** | 1 Gbit/s (With SRU40) 2 Gbit/s (With SRU80) 1 Gbit/s (With SRU100E) 4.5 Gbit/s (With SRU200) |
Firewall Performance (large packets) | 5.5 Gbit/s (With SRU40) 9.5 Gbit/s (With SRU80) 10 Gbit/s (With SRU100E) 15 Gbit/s (With SRU200) |
Number of recommended users | 1,000 |
Fixed WAN Ports | SRU40: 3 x GE (2 x Combo) SRU80: 3 x GE (2 x Combo) SRU100E: 4 x GE Combo+ 2 x GE SFP SRU200: 4 x GE Combo+ 2 x 10 GE SFP+ |
SIC Slots | 4 |
WSIC Slots (default/max**) | 2/4 |
XSIC Slots (default/max**) | 2/4 |
EXSIC Slot (shared with XSIC slots) | 1 |
DSP Slots | 0/3 |
USB 2.0 Ports | 1/2 |
Mini-USB Ports | 1 |
Console Port | 1 |
Memory | 2 GB/4 GB |
Flash(default/max**) | 2 GB/8 GB |
