Item

Specification

Model

AR2220E

Part Number

02350DQM

Description

AR2220E (3GE WAN (1GE Combo), 2 USB, 4 SIC, 2 WSIC, 1 DSP DIMM, 150W AC Power)

System parameters

Processor

Quad-core, 1 GHz

Memory

1 GB

Flash

512 MB

Micro SD card (default: sd1)

2 GB

Hard disk

Not supported

Dimensions and weight

Dimensions (H x W x D)

With no mounting bracket installed: 44.5 mm x 442.0 mm x 420.0 mm (1.75 in. x 17.40 in. x 16.54 in.)

With mounting brackets installed: 44.5 mm x 482.6 mm x 420.0 mm (1.75 in. x 19.00 in. x 16.54 in.)

Weight

6 kg (13.23 lb)

Power specifications

Rated AC input voltage

100 V/240 V, 50 Hz or 60 Hz

Maximum input voltage range (AC)

90 V AC to 264 V AC, 47 Hz to 63 Hz

Maximum input current

3 A

Maximum output power

150 W

RPS power supply

Supported

PoE power supply

Not supported

Power consumption

Typical power consumption

27 W

Maximum power consumption

29 W

Heat dissipation

Fan module

Built-in fan module, not swappable

Airflow (facing the front panel)

Left-to-right

Interface density

Management interfaces

1 (RJ45)

CON/AUX interface

1 (RJ45)

USB 2.0 interfaces

2

Service interfaces (standard configuration)

WAN interfaces: one GE combo interface and two GE electrical interfaces

Extended slots

4xSIC

2xWSIC

DSP DIMM slot

Supported

Environment parameters

Operating temperature

0°C to 45°C (32°F to 113°F)

NOTE:

When the altitude is between 1800 m and 5000 m, the highest operating temperature reduces by 1°C every time the altitude increases by 220 m.

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Operating relative humidity

5% to 95%, noncondensing

Operating altitude

< 5000 m (16404.2 ft.)
