Item

Specification

Model

AR101GW-Lc-S

Part Number

50010367

Description

AR101GW-Lc-S-Huawei Enterprise 4G router, 1 GE WAN, 4 GE LAN

System parameters

Processor

Dual-core, 1 GHz

Memory

512 MB

Flash

512 MB

Micro SD card (default sd1)

None

Hard disk

Not supported

Dimensions and weight

Dimensions (H x W x D)

With no mounting bracket installed: 44.0 mm x 300.0 mm x 216.4 mm (1.73 in. x 11.81 in. x 8.52 in.)

With mounting brackets installed: 44.0 mm x 482.6 mm x 216.4 mm (1.73 in. x 19.00 in. x 8.52 in.)

Weight

2.8 kg (6.17 lb)

Power specifications

Rated input voltage (AC)

100 V to 240 V, 50 Hz/60 Hz

Maximum input voltage range (AC)

90 V to 264 V, 47 Hz to 63 Hz

Maximum output current

2 A

Maximum output power

24 W

RPS power supply

Not supported

PoE power supply

Not supported

Power consumption

Maximum power consumption

9.3 W

Heat dissipation

Fans

None

Airflow (facing the front panel)

None

Interface density

Management interfaces

1 (RJ45)

CON/AUX interfaces

1 (RJ45)

USB 2.0 interfaces

1

Service interfaces

WAN interface: one GE electrical interface

LAN interfaces: four GE electrical interfaces

Extended slots

Not supported

Environment parameters

Operating temperature

0°C to 45°C (32°F to 113°F)

NOTE:

When the altitude is 1800 m-5000 m (5906ft.-16404.2 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Operating relative humidity

5% to 95%, noncondensing

Operating altitude

< 5000 m (16404.2 ft.)
