Huawei OptiXstar S800E XGS-PON SFP ONU GE/2.5 GE/5 GE/10 GE

USD

412

5 5/5.0 Reviews Q/A 4 Sold/Mon
Detail:	Huawei OptiXstar S800E XGS-PON SFP ONU, 1 XGS-PON (SC/APC), GE/2.5 GE/5 GE/10 GE
Model:	OptiXstar S800E
Condition:	Factory Sealed New
Related:
Warranty:	3-Years Warranty 100% Money-back Free After-Sales Service
Shipping:	Air Shipping to United States , Most Customers Receive during 5-7 Days ? If you finish the payment today, your order will arrive within the estimated delivery time.
Ships to: 0.2	2-7 Days US$
Payment:	Pay by wire transfer. Pay with your paypal. Pay with your Visa credit card. Pay with your Mastercard credit card. Pay with your Discover Card. Pay by Western Union. More

Description
Specification
Reviews
Q&A
Warranty
Download

Overview

Name: Huawei OptiXstar S800E XGS-PON SFP ONU GE/2.5 GE/5 GE/10 GE
Brand: hi-network
Rating: 5 (36 reviews)

Huawei OptiXstar S800E is a miniature Optical Network Unit (ONU) that can be inserted into the Small Form-Factor Pluggable (SFP) port of a camera or Access Point (AP) to provide 10-Gigabit-capable Symmetric Passive Optical Network (XGS-PON) access, meeting video or wireless backhaul requirements.

Quick Specification

Table 1 shows the Quick Specification.

Model	OptiXstar S800E
Dimensions (H x W x D)	12.6 x 13.6 x 65 mm
Weight (Without Power Adapter)	Approximately 27 g
Operating Temperature	–40°C to +85°C
Operating Humidity	5–95% RH (non-condensing)
System Power Supply	3.3 V
NNI	XGS-PON
UNI	GE/2.5 GE/5 GE/10 GE
Maximum Power Consumption	2 W

Figure 1 shows the appearance of OptiXstar S800E.

front-left-optixstar-s800e-datasheet

Product Details

Port Parameters

XGS-PON Port

● Port type: SC/APC

● Standard compliance: ITU-T G.9807

● Receiver sensitivity: ≤ –28 dBm

● Overload optical power: ≥ –9 dBm

● TX optical power: 4–9 dBm

● Extinction ratio (ER): ≥ 6 dB

● Transmission rate: RX: 9.953 Gbit/s; TX: 9.953 Gbit/s

● TX wavelength range: 1260–1280 nm (Center wavelength: 1270 nm)

● RX wavelength range: 1575–1580 nm (Center wavelength: 1577 nm)

Product Function

Smart O&M	● Variable-length OMCI messages ● Rogue ONT detection and isolation from the OLT ● PPPoE/DHCP simulation testing
Multicast	● IGMP v2/v3 snooping ● MLD v1/v2 snooping ● Fast leave ● VLAN tag translation, transparent transmission, and removal for downstream multicast packets ● IGMP/MLD protocol packet rate limitation
Common O&M	● OMCI ● Dual-system software backup and rollback ● 802.1ag Ethernet OAM ● Optical link measurement and diagnosis
Security	● MAC address filtering
QoS	● Ethernet port rate limitation ● 802.1p priority ● SP/WRR/SP+WRR ● Broadcast packet rate limitation ● Flow mapping based on the VLAN ID, port ID, or/and 802.1p

Get More Information

Do you have any question about the OptiXstar S800E?

Specific Data Sheet:

OptiXstar S800E Specification
Dimensions (H x W x D)	12.6 x 13.6 x 65 mm
Weight (Without Power Adapter)	Approximately 27 g
Operating Temperature	–40°C to +85°C
Operating Humidity	5–95% RH (non-condensing)
System Power Supply	3.3 V
NNI	XGS-PON
UNI	GE/2.5 GE/5 GE/10 GE
Maximum Power Consumption	2 W
XGS-PON Port	● Port type: SC/APC ● Standard compliance: ITU-T G.9807 ● Receiver sensitivity: ≤ –28 dBm ● Overload optical power: ≥ –9 dBm ● TX optical power: 4–9 dBm ● Extinction ratio (ER): ≥ 6 dB ● Transmission rate: RX: 9.953 Gbit/s; TX: 9.953 Gbit/s ● TX wavelength range: 1260–1280 nm (Center wavelength: 1270 nm) ● RX wavelength range: 1575–1580 nm (Center wavelength: 1577 nm)
