Huawei OptiXstar F600C GPON ONU 1 GE Wi-Fi 6

142
5
5/5.0
Q/A
11 Sold/Mon
Detail: Huawei OptiXstar F600C-30-1GH, a Wi-Fi 6 ONU, GPON (XC/UPC), 1 GE + 2.4 GHz & 5 GHz Wi-Fi 6
Model: OptiXstar F600C
Condition: Factory Sealed New
Related:
Warranty:
3-Years Warranty
100% Money-back
Free After-Sales Service
Shipping:
Air Shipping to United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
Ships to:
0.6
2-7 Days US$
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Quantity
- +
add to Cart quick quote
add to Cart quick quote
  • Description
  • Specification
  • Reviews
  • Q&A
  • Warranty
  • Download

Overview


Huawei OptiXstar F600C-30-1GH is an ONU that supports Wi-Fi 6 for enterprises. It provides ultra-broadband access through optical fibers in the upstream direction and works with a primary gateway device to realize gigabit Wi-Fi coverage for enterprises.


Quick Specification


Table 1 shows the Quick Specification.

Model

F600C-30-1GH

Dimensions (H x W x D)

Panel: 86 mm x 86 mm x 9.5 mm

Internal module depth: 35 mm

Weight

168 g

Operating Ambient Temperature

-5°C - 40°C

Operating Ambient Humidity

5% RH to 95% RH, non-condensing

Power Supply of The Entire System

100–240 V AC, 50/60 Hz

Network-side Ports

● Network side: 1*GPON

User-side Ports

● User side: 2*GE

Static Power Consumption

7.2 W

Maximum Power Consumption

7.2 W

Surge Protection Specifications

● GE: 4 kV in common mode and 0.5 kV in differential mode

● AC power supply: 6 kV in common mode and 4 kV in differential mode


Figure 1 shows the appearance of OptiXstar F600C.


front-optixstar-f600c-30-1gh-datasheet


Highlight

● Supports Wi-Fi 6, 160 MHz frequency band, and an air interface rate of 3 Gbit/s. The maximum test rate reaches 1.2 Gbit/s.

● Based on the OFDMA technology, a single secondary device supports 64 concurrent connections.

● Supports seamless Wi-Fi roaming with a handover latency about 100 ms.

● Photoelectric composite cables supply power to remote secondary devices, eliminating difficulties in power acquisition.

● Features high efficiency and stability, strong anti-interference capability, and wide coverage.



Product Details


Interface Parameters

Optical Port

● Downstream rate: 2.488 Gbit/s; upstream rate: 1.244 Gbit/s

● Plug-and-play

Gigabit Ethernet Port

● MAC address limit

● MAC address learning

● 10 Mbit/s, 100 Mbit/s, and 1000 Mbit/s auto-sensing


Product Function


MiniFTTO Networking Scenario

Optical port

● Downstream rate: 2.488 Gbit/s; upstream rate: 1.244 Gbit/s

● Plug-and-play

Smart connectivity

● Upstream transmission modes: optical fiber

● Working mode: bridge mode

O&M

● Web UI

● Software dual-backup and rollback

*: User terminals must support 802.11k/802.11v.


FTTO Networking Scenario

Automatic Service Provisioning

● Authentication-free

● XML/OMCI/TR069

Multicast

● IGMP v2/v3 snooping

● Dynamic controllable multicast

● IGMP proxy

● MLDv1/MLDv2 snooping

Intelligent O&M

● XML/Web UI

● Rogue ONT Detection and Self-regulation

● Ring network detection

● PPPoE emulation/DHCP emulation

Qos

● Ethernet port rate limit

● 802.1p priority

● SP/WRR/SP+WRR

Layer 3 Features

● Default/Static/Policy/Ser vice route

● VLAN binding

● ALG/UPnP/ARP

● DDNS/DMZ/DNS/NAPT

● PPPoE/Static IP/DHCP

● Port mapping/Port trigger

● IPv6

Layer 2 Management

● DHCP Option82

● PITP

● BPDU transparent transmission

● LLDP

Security

● 802.1x

● IPv6/IPv4 firewall

● MAC address filtering/IP address filtering

● Anti-DoS/ARP attack

● Static MAC address binding

● Device Access Control

Networking Protection

● Type B single-homing protection

● Type B dual-homing protection


Wi-Fi Specifications

Supported Protocol

IEEE 802.11 ax (2.4GHz&5GHz)

MIMO

2 x 2 MIMO (2.4 GHz & 5 GHz)

Antenna Gain

5 dBi

Air Interface Rate

574 Mbps (2.4 GHz)

2402 Mbps (5 GHz)

Maximum Tx Power

23 dBm

NOTE: The actual Tx power varies with local laws and regulations.

Frequency Band

20/40/80/160 MHz

Others

1024-QAM, WPA3, DL MU MIMO


Get More Information

Do you have any question about the OptiXstar F600C?

Contact us now via [email protected].

Specific Data Sheet:


OptiXstar F600C Specification

Dimensions (H x W x D)

38 mm x 200 mm x 200 mm

Weight (Excluding Adapter)

About 0.6kg

Power Supply

12 V DC, 1.5 A (power obtained through adapter)

56 V DC, 0.25 A (POF* power supply)

*POF refers to photoelectric composite cable.

Rated Input Range of Power Adapter

100~240 V AC, 50/60 Hz

Static Power Consumption

6W

Maximum Power Consumption

11W

Fiber Port

GPON upstream transmission (port type: XC/UPC)

Button

Reset button

Network-Side Ports

GPON

User-Side Ports

1 GE + 2.4 GHz & 5 GHz Wi-Fi 6

Indicator

One WLAN running indicator

Operating Temperature

– 10°C to +50°C

Operating Humidity

5%–95% RH, non-condensing

Installation Mode

Ceiling-mounted installation

Optical Port

● Downstream rate: 2.488 Gbit/s; upstream rate: 1.244 Gbit/s

● Plug-and-play

Gigabit Ethernet Port

● MAC address limit

● MAC address learning

● 10 Mbit/s, 100 Mbit/s, and 1000 Mbit/s auto-sensing
