Product Number

FPR2130-ASA-K9

Product Description

Cisco Firepower 2130 ASA Appliance, 1RU, 1 x Network Module Bays

ASA Performance and Capabilities on Firepower Appliances

Stateful inspection firewall throughput

10 Gbps

Stateful inspection firewall throughput (multiprotocol)

5 Gbps

Concurrent firewall connections

2 million

New connections per second

40000

IPsec VPN throughput (450B UDP L2L test)

1 Gbps

IPsec/Cisco AnyConnect/Apex site-to-site VPN peers

7500

Maximum number of VLANs

750

Security contexts (included; maximum)

2; 30

High availability

Active/active and active/standby

Scalability

VPN Load Balancing

Centralized management

Centralized configuration, logging, monitoring, and reporting are performed by Cisco Security Manager or alternatively in the cloud with Cisco Defense Orchestrator

Adaptive Security Device Manager

Web-based, local management for small-scale deployments

Hardware Specifications

Dimensions (H x W x D)

1.73 x 16.90 x 19.76 in. (4.4 x 42.9 x 50.2 cm)

Form factor (rack units)

1RU

I/O module slots

1 NM slot

Integrated I/O

12 x 10M/100M/1GBASE-T Ethernet interfaces (RJ-45), 4 x 10 Gigabit (SFP+) Ethernet interfaces

Network modules

(FPR-NM-8X10G) 8 x 10 Gigabit Ethernet Enhanced Small Form-Factor Pluggable (SFP+) network module

Maximum number of interfaces

Up to 24 total Ethernet ports (12x1G RJ-45, 4x10G SFP+, and network module with 8x10G SFP+)

Integrated network management ports

1 x 10M/100M/1GBASE-T Ethernet port (RJ-45)

Serial port

1 x RJ-45 console

USB

1 x USB 2.0 Type-A (500mA)

Storage

1x 200 GB, 1x spare slot (for MSP)

Power supplies

Configuration

Single integrated 250W AC power supply.

AC input voltage

100 to 240V AC

AC maximum input current

< 6A at 100V

AC maximum output power

400W

AC frequency

50 to 60 Hz

AC efficiency

>89% at 50% load

DC input voltage

-48V to -60VDC

DC maximum input current

< 12.5A at -48V

DC maximum output power

350W

DC efficiency

>88% at 50% load

Redundancy

1+1 AC or DC with dual supplies

Fans

1 hot-swappable fan module (with 4 fans)

Noise

56 dBA @ 25C

77 dBA at highest system performance.

Rack mountable

Yes. Mount rails included (4-post EIA-310-D rack)

Weight

19.4 lb (8.8 kg) 1 x power supplies, 1 x NM, 1 x fan module, 2x SSDs

Temperature: operating

32 to 104°F (0 to 40°C) or NEBS operation (see below)

Temperature: nonoperating

-4 to 149°F (-20 to 65°C)

Humidity: operating

10 to 85% noncondensing

Humidity: nonoperating

5 to 95% noncondensing

Altitude: operating

10,000 ft (max) or NEBS operation (see below)

Altitude: nonoperating

40,000 ft (max)

NEBS operation

Operating altitude: 0 to 13,000 ft (3962 m)

Operating temperature:

Long term: 0 to 45°C, up to 6,000 ft (1829 m)

Long term: 0 to 35°C, 6,000 to 13,000 ft (1829 to 3964 m)

Short term: -5 to 55°C, up to 6,000 ft (1829 m)
