| Detail: | Fiberhome HG6821M ONU, GPON Terminal with 4GE+2POTS+1CATV+1USB+2.4G/5G Wi-Fi |
| Model: | HG6821M |
| Condition: | Factory Sealed New |
| Related: | |
| Warranty: |
1-Year Warranty
100% Money-back
Free After-Sales Service
|
| Shipping: |
Air Shipping to
United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the estimated delivery time. |
| Ships to:
1
|
2-7 Days
US$
|
| Payment: |
More
|
Fiberhome HG6821M ONU is GPON Optical Network Terminal (ONT) and designed for HGU (Home Gateway Unit) in FTTH applications. Fiberhome HG6821M ONU supports L3 function to help subscriber construct the intelligent home network. Fiberhome HG6821M provides a GPON interface to connect OLT with an ODN. It offers a new choice for operators to deliver FTTH access.
Model | HG6821M |
Description | HG6821M ONU, GPON Terminal with 4GE+2POTS+1CATV+1USB+2.4G/5G Wi-Fi |
Ports | 4GE+2POTS+1CATV+1USB+Wi-Fi |
Dimensions (H x W x D) (mm) | 220 mm x 160 mm x 32 mm |
Weight | < 1000 g |
Operating temperature | 0°C to +40°C |
Operating humidity | 5% RH to 95% RH (non-condensing) |
Power adapter input | 100–240 V AC, 50–60 Hz |
System power supply | 11–14 V DC, 0.5 A |
Static power consumption | 7.5 W |
Max power consumption | 18 W |
Indicators | POWER/PON/LOS/LAN/TEL/USB/WLAN/WPS/CATV |
Smart Wi-Fi sharing:
Portal/802.1x authentication
SoftGRE-based sharing
Association of one account with two POTS ports
Smart Wi-Fi coverage
SIP/H.248 auto-negotiation
Any port any service
Parental control (V300R015C00)
L2/L3(IPv4) forwarding: 1G uplink, 2G downlink
PPPoE/Static IP/DHCP
Port forwarding
DDNS/DNS server/DNS client
IPv6/IPv4 dual-stack, and DS-Lite
Static/Default routes
Multiple services on one WAN port
Do you have any questions about the HG6821M?
Contact us now via [email protected].
Specific Data Sheet:
HG6821M Specification | |
Description | HG6821M ONU, GPON Terminal with 4GE+2POTS+1CATV+1USB+2.4G/5G Wi-Fi |
Ports | 4GE+2POTS+1CATV+1USB+Wi-Fi |
Dimensions (H x W x D) (mm) | 220 mm x 160 mm x 32 mm |
Weight | < 1000 g |
Operating temperature | 0°C to +40°C |
Operating humidity | 5% RH to 95% RH (non-condensing) |
Power adapter input | 100–240 V AC, 50–60 Hz |
System power supply | 11–14 V DC, 0.5 A |
Static power consumption | 7.5 W |
Max power consumption | 18 W |
Indicators | POWER/PON/LOS/LAN/TEL/USB/WLAN/WPS/CATV |
What is Guaranteed.
After receiving your order, take a full month to try it out. If you find quality is not good, we'll take it back and refund your money. Your complete satisfaction is GUARANTEED or your money back. That's guaranteed.
After your order items which are available. We will use most fast delivery way to global countries. Normally we will ship out cargos during 3 -5 days. And international delivery will take about 3- 10 days according to your location.
Service Never Ends.
Hardwares Warrany Time:
Original New Sealed Hardware: 3 Years
Refurbished/Used Original Devices: 1 Year
After warranty time, you also can contact us to return back for repair service. Everything you purchase from HI-NETWORK.COM. We will offer lifetime online service support for your any possible questions.
