Product specifications

Multiservice access support

– IPTV services

– Multimedia services

– High-speed internet access (HSIA)

– Business access

– Cell site backhaul support

– 8-port GPON using 8 dual GPON SFP optics that is fully compliant to ISAM FXOLT

Network Termination (NT) support

– 40 Gb/s switching capacity

– Link aggregation (LAG)

– 20 Gb/s uplink capacity

– SFP+ cages

Management

• Fully managed by the Nokia 5520 Access Management System (AMS)

• Simple Network Management Protocol (SNMP) and command line interface (CLI)- based management system

Eco-sustainability

• Power consumption targets code of conduct (CoC) power consumption limits

• Compliant with the European directive 2002/95/ EC on the restriction of the use of certain hazardous substances (RoHS)

• Product collection and treatment under Nokia responsibility complies with the national laws on product treatment applied at the end of life for wastes from electrical and electronic equipment (WEEE), implementing the European Directive (2002/96/EC)

• Product packaging materials are free from hydrochlorofluorocarbons (HCFCs)

• Plastic product packaging material is marked according to ISO 11469, referring to ISO 1043 (97/129/EEC)

Standard compliance

Environmental

– ETS EN 300 019-1-1 storage

– Class 1.1, weather-protected, partly temperaturecontrolled locations ETS EN 300 019-1-2 transport

– Class 2.3, public transportation

– ETS EN 300 019-1-3 stationary use

– Class 3.3 and Class 3.4

– ETS EN 300 132-2

Protection

ITU-T K.20 enhanced and K.45 basic

Safety

– IEC 60950, EN 60950 Class 1, AS/NZS 60950.1

– UL/CSA 60950-1

EMC

– ETS EN 300 386 for telecommunications center installation environment

– ETS ES 201 468

– EN 55022

Acoustic noise

– ETS 300 753

Operating environment

• Temperature: -40⁰C to 65⁰C (-40⁰F to 149⁰F)

• Relative humidity: 5% to 93%, non-condensing

• Over-temperature sensors and shutdown

Power

– AC power: 85 V to 280 V AC, 47 Hz to 63 Hz with battery backup

– DC power: -36 V DC to -72 V DC using redundant DC power inputs

Dimension

Height: 44 mm (1 RU) (1.7 in)

Width: 442 mm (17.4 in)

Depth: 267.5 mm (10.5 in), including optical modules and fan tray handle
