Used Cisco WS-X4748-SFP-E Catalyst 48-port Nonblocking SFP

5045 $35000 (85.6% OFF)
4.9
4.9/5.0
Q/A
3 sold/Mon
Detail: Cisco 4500 Line Card WS-X4748-SFP-E Catalyst 4500 E-Series 48-port Nonblocking SFP
Model: WS-X4748-SFP-E
Condition: Used
Related:
Warranty:
3 Years-Warranty
100% Money-back
Free After-Sales Service
Shipping:
Air Shipping to United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
Ships to:
18.5
2-7 Days US$
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Quantity
- +
add to Cart quick quote
add to Cart quick quote
  • Description
  • Specification
  • Reviews
  • Q&A
  • Warranty
  • Download

Used Cisco WS-X4748-SFP-E Catalyst 48-port Nonblocking SFP

(Note:  Cisco discount and Stock always changed, we will try most effort to follow it but can not ensure every web was  changed accordingly.  So Our Products Service will contact you after order if meet such special condition.)


Cisco Catalyst WS-X4748-SFP-E line-card is designed for requiring line-rate capability for enterprise, mid-market and commercial core and distribution deployments. Integrated 48 SFP nonblocking ports with IEEE802.1AE Fiber Encryption and Cisco TrustSec capability in hardware, WS-X4748-SFP-E line-card delivers high-performance and secures user experience. This WS-X4748-SFP-E is similar with the WS-X4748-SFP-E=. The WS-X4748-SFP-E= is a spare one.


Quick Specification:


Product Code

WS-X4748-SFP-E

Line-Card Type

Cisco Catalyst 4500 47xx E‑Series Line Cards

Per-Slot Bandwidth

48 Gbps

Chassis Support

Cisco Catalyst 4503-E, 4506-E, 4507R+E, and 4510R+E

Supervisor Support

Supervisor Engine 8-E,

Supervisor Engine 8L-E,

Supervisor Engine 7-E,

Supervisor Engine 7L-E

per-slot capacity

48 gigabits

Max Rated Power (W)

92

Rated MTBF (Hours)

876,100

 Modules

·48 * SFP Gigabit nonblocking Ethernet ports
·Support 1G/100FX SFP (mix and match as well) at line rate

Cisco IOS Software

Cisco IOS Software Release IOS-XE3.5.0E/15.2(1)E or later

hardware

IEEE 802.1AE Fiber Encryption and Cisco TrustSec capability in hardware

Enterprise

Providing Fiber to the Desktop (FTTD), for deployments where non-blocking is mandatory requirement

Service provider

GE aggregation for DSLAM/PON/mobile data backhaul; Point-to-Point fiber to the home (FTTH) or building (FTTB) for residential and business applications

L2-4 Jumbo Frame support

Up to 9216 bytes

·All power numbers shown in Table 1 are maximum values recommended for facility power and cooling capacity planning. These figures are not indicative of the actual power draw during operation. Typical power draw is about 20 percent lower than the maximum value shown.


Product Details:

ws-x4748-sfp-e-datasheet

Compare To Similar Items:


Product Code

WS-X4748-SFP-E

WS-X4712-SFP-E

WS-X4712-SFP+E

Line-Card Type

Cisco Catalyst 4500 47xx E‑Series Line Cards

Cisco Catalyst 4500 47xx E‑Series Line Cards

Cisco Catalyst 4500 47xx E‑Series Line Cards

Per-Slot Bandwidth

48 Gbps

48 Gbps

48 Gbps

Chassis Support

Cisco Catalyst 4503-E, 4506-E, 4507R+E, and 4510R+E

Cisco Catalyst 4503-E, 4506-E, 4507R+E, and 4510R+E

Cisco Catalyst 4507R-E and 4510R-E

per-slot capacity

48 gigabits

12 gigabits

48 gigabits

Max Rated Power (W)

92

25

90

Rated MTBF (Hours)

876,100

1,329,480

387,172

 Modules

·48 * SFP Gigabit nonblocking Ethernet ports
·Support 1G/100FX SFP (mix and match as well) at line rate

 ·12 Port nonblocking SFP line card
·Support 1G/100FX SFP (mix and match as well) at line rate

 ·Up to 12 ports 10GE SFP+ (10GBASE-R) or 12 ports GE SFP (1GBASE-X)
·SFP+ and SFP can be used simultaneously on the same line card without any restrictions


Get More Information

Do you have any question about the WS-X4748-SFP-E?

Contact us now via [email protected]


Specific Data Sheet:


Type

E-Series Gigabit Ethernet SFP Line Cards

Number of Ports

48

Port Speed

1GbE/100Mbps

Port Type

Pluggables

Wire Rate

1:1

Standards

●  Gigabit Ethernet: IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab, IEEE 803.3at, IEEE 802.3af, IEEE 802.3az

●  1000BASE-X (GBIC), 1000BASE-SX, 1000BASE-LX/LH, 1000BASE-ZX, CWDM

EtherChannel Technology

●  Gigabit EtherChannel: All 1000 Mbps ports

●  10 Gigabit EtherChannel: All 10Gbps ports

●  IEEE 802.3ad (Link Aggregation Control Protocol): All 1000 Mbps ports

●  Port Aggregation Protocol (PagP): Yes

●  Number of ports per tuple: 8

●  EtherChannel and IEEE 802.3ad technology across line cards: Yes

Physical Dimensions

●  Occupies one slot in the Cisco Catalyst 4500 Series platform

●  Dimensions (H x W x D): 1.2 x 14.25 x 10.75 in. (3.0 x 36.2 x 27.3 cm)

Environmental Conditions

●  Operating temperature: 32° to 104°F (0° to 40°C)

●  Storage temperature: -40° to 167°F (-40° to 75°C)

●  Relative humidity: 10 to 90%, noncondensing

●  Operating altitude: -60 to 3000m

Safety Conditions

Fiber optic lasers: Class 1 laser products

Safety Certifications

●  UL 1950

●  EN 60950

●  CSA-C22.2 no 950

●  IEC 950

●  IEC 60950-1, 2nd Ed. EN 60950-1, 2nd Ed. UL 60950-1, 2nd Ed. CAN/CSA-C22.2 No. 60950-1 2nd Ed.11

Electromagnetic Emissions Certifications

●  FCC 15J Class A

●  VCCI Class A

●  CE Marking

●  EN 55022 Class A

●  EN 55024 Class A

●  CISPR 22 Class A

●  AS/NZ 3548

●  NEBS Level 3 (GR-1089-CORE, GR-63-CORE)

●  ETSI ETS-300386-2

●  EN 50121-4

ROHS Compliance

ROHS5

Max Rated Power (W)

92

Rated MTBF (Hours)

876,100
