| Detail: | Nexus 3164Q, 64 QSFP+ ports, 2RU switch |
| Model: | N3K-C3164Q-40GE |
| Condition: | Facotry Sealed New, In Stock |
| Related: | |
| Warranty: |
3 Years - Warranty
100% Money-back
Free After-Sales Service
|
| Shipping: |
Air Shipping to
United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the estimated delivery time. |
| Ships to:
21
|
2-7 Days
US$
|
| Payment: |
More
|
(Note: Cisco discount and Stock always changed, we will try most effort to follow it but can not ensure every web was changed accordingly. So Our Products Service will contact you after order if meet such special condition.)
N3K-C3164Q-40GE is the Nexus 3164Q, 64 QSFP+ ports, 2RU switch. The Cisco Nexus 3164Q Switch is an ultra-high density, power efficient, 10/40-Gbps switch designed for the data center. This compact, two-rack-unit (2RU) model offers wire-rate Layer 2 and Layer 3 switching on all ports. It runs the enhanced version of the Cisco NX-OS Software operating system, that also supports Nexus 9000 series switches. It provides customer comprehensive features while simplifying image management. The rich programmability features enable organizations to run today’s applications while also being prepared for the demanding and changing application needs such as big data, cloud, and virtualization.
Model | N3K-C3164Q-40GE |
Physical | · 2 RU fixed form-factor switch · 64 QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes · 2 redundant power supplies · 3+1 redundant fans · Management, console, and USB flash-memory ports |
Performance | · 5.12 Tbps switching capacity · Forwarding rate up to 3.8 bpps · Line-rate traffic throughput (both Layer 2 and 3) on all ports · Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) |
Physical dimensions (H x W x D) | 3.48 x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
Weight | 37 lb (16.8kg) |
Model | Description |
QSFP-40G-SR-BD | Cisco QSFP40G BiDi Short-reach Transceiver |
QSFP-H40G-AOC1M | QSFP 40G Active Optical Cable 1m |
QSFP-H40G-AOC2M | QSFP 40G Active Optical Cable 2m |
QSFP-H40G-AOC3M | QSFP 40G Active Optical Cable 3m |
QSFP-H40G-AOC5M | QSFP 40G Active Optical Cable 5m |
QSFP-H40G-AOC7M | QSFP 40G Active Optical Cable 7m |
QSFP-H40G-AOC10M | QSFP 40G Active Optical Cable 10m |
QSFP-4X10G-AOC1M | QSFP to 4 x SFP 10Gbps Active Optical Cable 1m |
QSFP-4X10G-AOC2M | QSFP to 4 x SFP 10Gbps Active Optical Cable 2m |
QSFP-4X10G-AOC3M | QSFP to 4 x SFP 10Gbps Active Optical Cable 3m |
QSFP-4X10G-AOC5M | QSFP to 4 x SFP 10Gbps Active Optical Cable 5m |
QSFP-4X10G-AOC7M | QSFP to 4 x SFP 10Gbps Active Optical Cable 7m |
QSFP-4X10G-AOC10M | QSFP to 4 x SFP 10Gbps Active Optical Cable 10m |
QSFP-4SFP10G-CU5M | QSFP to 4 x SFP 10-Gbps passive copper splitter cable, 5m |
QSFP-4SFP10G-CU3M | QSFP to 4 x SFP 10-Gbps passive copper splitter cable, 3m |
QSFP-4SFP10G-CU1M | QSFP to 4 x SFP 10-Gbps passive copper splitter cable, 1m |
QSFP-H40G-CU3M | 40GBASE-CR4 passive copper cable, 3m |
QSFP-H40G-CU1M | 40GBASE-CR4 passive copper cable, 1m |
QSFP-40G-SR4 | 40GBASE-SR4 QSFP transceiver module with MPO connector |
QSFP-40G-CSR4 | 40GBASE-CSR4 QSFP+ transceiver module for MMF, MPO/MTP connector, 300 m reach with OM3 fiber |
QSFP-40GE-LR4 | 40GBASE-LR4 QSFP+ transceiver module for SMF, 4 CWDM lanes in 1310 nm window Muxed inside module, duplex LC connector, 10 km reach |
N9K-C9300-FAN3 | Nexus 9300 Fan Module, Port side intake, Spare |
N9K-PAC-1200W | Nexus 3164 1200W AC Power Supply, Port side intake |
L-N3K-LAN1K9= | Nexus 3000 LAN Enterprise License, eDelivery |
Product Code | N3K-C3164Q-40GE | N3K-C3264Q |
Ports | 64 QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes | 64 QSFP+ ports; each supports native 40 Gigabit Ethernet |
Physical dimensions (H x W x D) | 3.48 x 17.41 x 22.32in. (88.4 x 442 x 566 mm) | 3.39 x 17.41 x 22.32 in. (88.4 x 442 x 566 mm) |
Weight | 37 lb (16.8kg) | 32.8 lb (14.9 kg) |
Do you have any question about the N3K-C3164Q-40GE?
Contact us now via [email protected]
Physical | · 2 RU fixed form-factor switch · 64 QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes · 2 redundant power supplies · 3+1 redundant fans · Management, console, and USB flash-memory ports | |
Performance | · 5.12 Tbps switching capacity · Forwarding rate up to 3.8 bpps · Line-rate traffic throughput (both Layer 2 and 3) on all ports · Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) | |
Hardware tables and scalability | Number of VLANS | MSTP: 4096 |
Number of spanning-tree instances | MSTP: 64 RPVST+: 507 | |
Number of access control list (ACL) entries | 4000 to 16000 ingress 1000 to 4000 egress | |
Routing table | Maximum number of longest prefix match (LPM) routes 128,000 Maximum number of IP host entries 120,000 Maximum number of MAC address entries 96,000 | |
Number of EtherChannels | 256 | |
Number of ports per EtherChannel | 32 | |
Buffer size | 48 MB shared | |
System memory | 16 GB | |
Power | Frequency | 50 to 60 Hz |
Power supply types | AC | |
Typical operating power | 803 Watts (W) with SR4 optics at 100% load; 2 PSUs | |
Maximum power | 1100 Watts (W) | |
AC PSUs · Input voltage · Frequency · Efficiency |
· 200 to 240 VAC · 50 to 60 Hz · 93% at 220V | |
Typical heat dissipation | 2739 BTU/hr (with SR4 optics at 100% load) | |
Maximum heat dissipation | 3753 BTU/hr | |
Cooling | Port-side intake and port-side exhaust options Port-side intake: Yes Port-side exhaust: Post FCS | |
Dimensions | · Dimensions (height x width x depth) | 3.48 x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
Environment | Weight | 37 lb (16.8kg) |
Operating temperature | 32 to 104°F (0 to 40°C) | |
Storage temperature | -40 to 158°F (-40 to 70°C) | |
Operating relative humidity | · 10 to 85% noncondensing · Up to 5 days at maximum (85%) humidity Recommend ASHRAE data center environment | |
Storage relative humidity | 5% to 95% noncondensing | |
Altitude | 0 to 10,000 ft (0 to 3000m) | |
