Model

S5735-S48P4XE-V2

Part Number

98012053

Description

S5735-S48P4XE-V2 (48*10/100/1000BASE-T ports, 4*10GE SFP+ ports, 2*12GE stack ports, PoE+, without power module)

Dimensions without packaging (H x W x D) [mm(in.)]

Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.40 in. x 17.56 in.)

Dimensions with packaging (H x W x D) [mm(in.)]

185 mm x 650 mm x 550 mm (7.28 in. x 25.59 in. x 21.65 in.)

Chassis height [U]

1 U

Weight without packaging [kg(lb)]

5.20 kg (11.46 lb)

Weight with packaging [kg(lb)]

8.00 kg (17.64 lb)

Typical power consumption [W]

54.51 W

Typical heat dissipation [BTU/hour]

185.99 BTU/hour

Maximum power consumption [W]

- Without PoE:

62.90 W (with two 600 W AC power modules)

67.20 W (with two 1000 W AC power modules)

76.93 W (with two 1000 W DC power modules)

- Full PoE load:

1931.44 W (PoE: 1680 W, with three 1000 W AC power modules)

Maximum heat dissipation [BTU/hour]

- Without PoE:

214.62 (with two 600 W AC power modules)

227.93 (with two 1000 W AC power modules)

261.47 (with two 1000 W DC power modules)

- Full PoE load:

6590.27 (PoE: 1680 W, with three 1000 W AC power modules)

Static power consumption [W]

33.99 W

MTBF [years]

79.02 years

MTTR [hours]

2 hours

Availability

> 0.99999

Noise at normal temperature (acoustic power) [dB(A)]

Three 600 W AC PoE power modules with 30% load: 50 dBA

Three 1000 W AC PoE power modules with 30% load: 49.9 dBA

Three 1000 W DC PoE power modules with 30% load: 48.5 dBA

Noise at normal temperature (acoustic pressure) [dB(A)]

Three 600 W AC PoE power modules with 30% load: 38 dBA

Three 1000 W AC PoE power modules with 30% load: 37.9 dBA

Three 1000 W DC PoE power modules with 30% load: 36.5 dBA

Number of card slots

0

Number of power slots

3

Number of fans modules

2

Redundant power supply

1+1+1

Pluggable AC and DC power modules can be used together on the same device.

Long-term operating temperature [°C(°F)]

-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)

Restriction on the operating temperature variation rate [°C(°F)]

When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Devices cannot start when the temperature is lower than 0°C (32°F).

Storage temperature [°C(°F)]

–40°C to +70°C (–40°F to +158°F)

Long-term operating relative humidity [RH]

5% RH to 95% RH (non-condensing)

Long-term operating altitude [m(ft.)]

0–5000 m (0–16404 ft.)

Storage altitude [m(ft.)]

0-5000 m (0-16404 ft.)

Power supply mode

Pluggable power supply

Rated input voltage [V]

AC input: 100 V AC to 130 V AC, 200 V AC to 240 V AC; 50/60 Hz

High-voltage DC input: 240 V DC

DC input: –48 V DC to –60 V DC

Input voltage range [V]

AC input: 90 V AC to 290 V AC; 45–65 Hz

High-voltage DC input: 190 V DC to 290 V DC

DC input: -38.4 V DC to -72 V DC

Maximum input current [A]

The current specifications are related to the pluggable power module. For details, see Pluggable Power Modules.

Memory

2 GB

Flash memory

Physical space: 1 GB

Console port

RJ45

Eth Management port

Not supported

USB

Supported

RTC

Not supported

RPS input

Not supported

Service port surge protection [kV]

Common mode: ±6 kV

Power supply surge protection [kV]

Configured with AC power modules: ±6 kV in differential mode and ±6 kV in common mode

Configured with DC power modules: ±2 kV in differential mode and ±4 kV in common mode

Ingress protection level (dustproof/waterproof)

IP20

Types of fans

Built-in

Heat dissipation mode

Air cooling for heat dissipation, intelligent fan speed adjustment

Airflow direction

Air intake from left, front, and right and air exhaust from rear

PoE

Supported

Certification

EMC certification

Safety certification

Manufacturing certification
