Model

S5700-52P-LI-DC

Part Number

02353830

Description

48 Ethernet 10/100/1000 ports, 4 Gig SFP, DC -48V

Memory (RAM)

256 MB

Flash

V200R001: 64 MB

V200R002 and later versions: 200 MB

Mean time between failures (MTBF)

39.26 years

Mean time to repair (MTTR)

2 hours

Availability

> 0.99999

Service port surge protection

Common mode: ±6 kV

Power supply surge protection

±1 kV in differential mode, ±2 kV in common mode

Dimensions (H x W x D)

43.6 mm x 442.0 mm x 310.0 mm (1.72 in. x 17.4 in. x 12.2 in.)

Weight (with packaging)

3.5 kg (7.72 lb)

Stack port

V200R010 and earlier versions: the last two uplink 1000BASE-X optical ports
V200R011 and later versions: four uplink 1000BASE-X optical ports

RTC

Supported

RPS

Supported

PoE

Not supported

Rated voltage range

-48 V DC to -60 V DC

Maximum voltage range

-36 V DC to -72 V DC

Maximum power consumption (100% throughput, full speed of fans)

48.3 W

Typical power consumption (30% of traffic load)
● Tested according to ATIS standard
● EEE enabled
● No PoE power consumption

30.3 W

Operating temperature

0°C to 50°C (32°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.)

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Noise under normal temperature (27°C, sound power)

< 43.8 dB(A)

Relative humidity

5% to 95%, noncondensing

Operating altitude

0-2000 m (0-6562 ft.)

Certification

EMC certification
Safety certification
Manufacturing certification
