SmartAX MA5800-X2 IEC
  • SmartAX MA5800-X2 IEC

Huawei SmartAX MA5800-X2 IEC (AC / DC Supply)

9068
4.8
4.8/5.0
Q/A
2 Sold/Mon
Detail: Huawei SmartAX MA5800-X2 IEC OLT has 2 Service Slot, Max 32 x GPON/EPON, 96 x GE/FE, 16 x 10G GPON/10G EPON, 16 x 10G GE, 64 x E1
Model: SmartAX MA5800-X2 IEC
Condition: Factory Sealed New
Related:
Warranty:
3-Years Warranty
100% Money-back
Free After-Sales Service
Shipping:
Air Shipping to United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
Ships to:
9.4
2-7 Days US$
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Quantity
- +
add to Cart quick quote
add to Cart quick quote
  • Description
  • Specification
  • Reviews
  • Q&A
  • Warranty
  • Download

Overview


Huawei MA5800 X2 IEC is a next generation, 40G capacity Optical line Terminal (OLT). This offers 2 service slots, each service slot has 200G throughput capacity, smoothly evolve to 40G/100G PON. Support up to 8 times MAC address and ARP table than MA5608T, makes service configuration and expansion more easily.

ma5800-x2-sheet

ma5800-x2-sheet2

Slot Type

Slot No.

Total

Control board (SCU) slot

2,3

2

Power board slot

0

1

Service board slot

1,2

2



Quick Specification


Model

Huawei SmartAX MA5800-X2 IEC

Full weight (with IEC mounting ears)

9.4kg

Dimensions

2U high and 19 inches wide

Dimensions (H x W x D)

Without hanging size: 442 0mmx268.7mmx88.1mm

With IEC specifications hanging size: 482 6mmx268.7mmx88.1mm

With ETSI specifications: 535.0mmx268.7mmx88. 1mm

Power supply

DC (dual power backup) turbulence + battery backup

Rated voltage

AC power supply: 110V/220V

DC power supply: -48V/-60V

Operating voltage range

DC power supply: -38.4V ~-72V

AC power supply: 100V ~ 240V

Maximum input current per channel

DC power supply: 20A

AC power supply: 8A


Appearance:

ma5800-x2-datasheet


Features Huawei SmartAX MA5800-X2 IEC provides:


★ Multi-media Gigabit aggregation
Uniform access aggregation of optical fibres, copper cables, and cable media through PON/P2P, transforming multi-media independent access networks into a unified architecture access network for unified access and aggregation And management to simplify network architecture and operation and maintenance.
★ 4K/8K/VR video experience
Single-frame MA5800 can meet 16,000 homes and enjoy 2nd, ultra-high-definition 4K/8K/VR video online; use distributed cache, with larger cache and video burst absorption capability, thus helping 4K/8K/VR video quick start or channel switching; VMOS/eMDI video surveillance can realize intelligent sensing and troubleshooting for 4K/8K/VR video experience, bringing the best network operation and maintenance experience and user service experience.
★ Multi-service virtualization common platform
The MA5800 has the intelligence and virtualization capabilities to logically fragment devices and network resources, virtualize one OLT into multiple OLTs and assign different virtual OLTs to different services such as homes. , enterprise, Internet of Things and other multi-service intelligent operations, which help to collect old OLT, reduce the number of CO rooms, reduce operating costs; virtualization can support network open and wholesale, achieve multi-ISP shared-access network, ensure new business fast Agile deployment for better business experience.


The Accessories For SmartAX MA5800-X2 IEC:

Boards and Fan Tray:


Model name

Description

H901MPSC

4 GE/10GE upstream transmission ports and supports load sharing. By default, MA5800 connects to the upstream network through the control board

H901NXED

Enhanced 8-port 10GE upstream interface board, supporting 10GE/GE Ethernet upstream transmission. NXED is used when upstream ports currently provided in MA5800 are not enough.

H901GPHF

16 GPON ports for access services

H901GPSF

16 GPON ports for home access services

H901XGHD

8 asymmetric 10G GPON ports for access services.

H901TWED

8 symmetric 10G GPON ports for access services.

H901EDSH

32-channel E1 upstream board, supporting native TDM mode.

H901OGHK

48-port aggregated GE/FE optical interface board, supporting up to 48 channels of GE/FE

H901OXHD

8-port aggregated 10GE optical interface board, supporting GE/10GE Ethernet aggregation.

H901PISA

 -48V DC input

H901PISB

one AC power input and supports battery for power backup.

H901FMSA

Supplier power to fans; controls and monitors the fans


Get more information

Do you have any question about the SmartAX MA5800-X2 IEC?

Contact us now via [email protected].

Specific Data Sheet:


Model

Huawei SmartAX MA5800-X2 IEC

Full weight (with IEC mounting ears)

9.4kg

Dimensions

2U high and 19 inches wide

Dimensions (H x W x D)

Without hanging size: 442 0mmx268.7mmx88.1mm

With IEC specifications hanging size: 482 6mmx268.7mmx88.1mm

With ETSI specifications: 535.0mmx268.7mmx88. 1mm

Power supply

DC (dual power backup) turbulence + battery backup

Rated voltage

AC power supply: 110V/220V

DC power supply: -48V/-60V

Operating voltage range

DC power supply: -38.4V ~-72V

AC power supply: 100V ~ 240V

Maximum input current per channel

DC power supply: 20A

AC power supply: 8A
