Model

AR6140-S

Part Number

02353BMU

Description

AR6140-S AC host, 5*GE RJ45, 4*GE SFP, 1*USB 3.0, 4*SIC

Installation type

Rack

Chassis height [U]

1 U

Dimensions without packaging (H x W x D) [mm(in.)]

Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 428.2 mm (1.75 in. x 17.4 in. x 16.86 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.4 mm x 442.0 mm x 431.2 mm (1.75 in. x 17.4 in. x 16.98 in.)

Dimensions with packaging (H x W x D) [mm(in.)]

175 mm x 550 mm x 710 mm (6.89 in. x 21.65 in. x 27.95 in.)

Weight with packaging [kg(lb)]

7.6 kg (16.72 lb)

Weight without packaging [kg(lb)]

5.05 kg (11.11 lb)

CPU

1.4 GHz, 4 Cores

Memory

2 GB

NAND Flash

1 GB

Console port

RJ45

RTC

Supported

LAN ports

2 x GE SFP, 3 x GE electrical

WAN ports

2 x GE SFP, 2 x GE electrical

Number of service board slots

4

MIC slots (default/maximum)

0/0

SIC slots (default/maximum)

4/4

WSIC slots (default/maximum)

0/2

XSIC slots (default/maximum)

0/0

Redundant MPUs

Not supported

RPS input

Not supported

PoE

Not supported

IP rating

IP20

MTBF [years]

55.27 years

MTTR [hours]

2 hours

Availability

0.9999958690

Typical power consumption [W]

26 W

Maximum power consumption [W]

32 W

Power supply mode

AC built-in

Number of power modules

2

Rated input voltage [V]

100 V to 240 V, 50 Hz/60 Hz

Input voltage range [V]

90 V to 264 V, 47 Hz to 63 Hz

Maximum input current [A]

2 A

Maximum output power [W]

60 W/70 W

To view the available maximum output power, run the display power command.

Redundant power supply

Dual power supplies in 1:1 backup mode

Types of fans

Built-in

Number of fan modules

2

Heat dissipation mode

Air cooling

Airflow

Left-to-right airflow

Noise at normal temperature (acoustic power) [dB(A)]

54 dB(A)

Long-term operating temperature [°C(°F)]

0°C to 45°C (32°F to 113°F)

NOTE:

When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Long-term operating relative humidity [RH]

5% RH to 95% RH, non-condensing

Long-term operating altitude [m(ft.)]

< 5000 m (16404.2 ft.)

Storage temperature [°C(°F)]

-40°C to +70°C (-40°F to +158°F)

Overtemperature alarm

Supported
