Model

AR6140-16G4XG

Part Number

02352MQU

Description

AR6140-16G4XG, 4*GE WAN, 4*SFP+, 12*GE LAN, 1*USB2.0, 4*SIC

Installation type

Rack

Chassis height [U]

1

Dimensions without packaging (H x W x D) [mm(in.)]

- Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 428.2 mm (1.75 in. x 17.4 in. x 16.86 in.)

- Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.4 mm x 442.0 mm x 450.2 mm (1.75 in. x 17.4 in. x 17.72 in.)

Dimensions with packaging (H x W x D) [mm(in.)]

225 mm x 550 mm x 530 mm (8.86 in. x 21.65 in. x 20.87 in.)

Weight with packaging [kg(lb)]

7.85 (17.27)

Weight without packaging [kg(lb)]

5.35 (11.77)

CPU

1.85 GHz, 16 Cores

Memory

4 GB

NAND Flash

1 GB

Console port

RJ45

RTC

Supported

LAN ports

12 x GE electrical

WAN ports

4 x 10GE SFP+, 4 x GE electrical

Number of service board slots

4

MIC slots (default/maximum)

0/0

SIC slots (default/maximum)

4/4

WSIC slots (default/maximum)

0/2

XSIC slots (default/maximum)

0/0

Redundant MPUs

Not supported

RPS input

Not supported

PoE

Not supported

IP rating

IP20

MTBF [years]

51.78

MTTR [hours]

2

Availability

0.9999955910

Typical power consumption [W]

50

Maximum power consumption [W]

60

Power supply mode

Pluggable AC

Number of power modules

2

Rated input voltage [V]

100 V to 240 V, 50 Hz/60 Hz

Input voltage range [V]

90 V to 264 V, 47 Hz to 63 Hz

Maximum input current [A]

3 A

Maximum output power [W]

150 W

Redundant power supply

Support double AC power supply (1 : 1 backup)

Types of fans

Built-in

Number of fan modules

3

Heat dissipation mode

Air cooling

Airflow

Left-to-right airflow

Noise at normal temperature (acoustic power) [dB(A)]

57.6

Long-term operating temperature [°C(°F)]

0°C to 45°C (32°F to 113°F)

Note: When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Long-term operating relative humidity [RH]

5% RH to 95% RH, non-condensing

Long-term operating altitude [m(ft.)]

< 5000 m (16404.2 ft.)

Storage temperature [°C(°F)]

-40°C to +70°C (-40°F to +158°F)

Overtemperature alarm

Supported
