Dimensions (H x W x D)

26 x 69 x 83 mm

Weight

Approximately 80 g

Operating Temperature

0–40°C

Operating Humidity

5–95% RH (non-condensing)

Power Adapter Input

100–240 V AC, 50/60 Hz

System Power Supply

12 V DC, 1 A

UNI

1 x GE

NNI

GPON

Maximum Power Consumption*

2.1 W

Maximum PoE Output Power

NA

Installation Mode

Desktop

Compliance Certification

CE

GPON Port

● SC/APC

● Class B+

● Receiver sensitivity: –27 dBm to –29 dBm

● Wavelengths: US 1310 nm, DS 1490 nm

● Wavelength Blocking Filter (WBF)

● Flexible mapping between the GEM port and TCONT

● GPON: consistent with the SN or password authentication defined in G.984.3

● Bi-directional FEC

● SR-DBA and NSR-DBA

Ethernet Electrical Port

● Ethernet port-based VLAN tags and tag removal

● 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission

● QinQ VLAN

● Limit on the number of learned MAC addresses

● MAC address learning

● Transparent transmission of IPv6 packets at Layer 2
