Model

AR207G-HSPA+7

First Supported Version

V200R002C01

Memory Size

512 MB

Flash Memory

512 MB

Processor

Dual-core, 533 MHz

Micro SD card (default: sd1)

None

Hard disk

Not supported

Dimensions (W x D x H)

With no mounting bracket installed: 44.0 mm x 300.0 mm x 216.4 mm (1.73 in. x 11.81 in. x 8.52 in.)

With mounting brackets installed: 44.0 mm x 482.6 mm x 216.4 mm (1.73 in. x 19.00 in. x 8.52 in.)

Weight

2.8 kg (6.17 lb)

Rated input voltage range (AC)

100 V to 240 V, 50 Hz/60 Hz

Maximum input voltage range (AC)

90 V AC to 264 V AC, 47 Hz to 63 Hz

Maximum output current

3 A

Maximum output power

36 W

RPS power supply

Not supported

PoE power supply

Not supported

Maximum power consumption

17.1 W

Fan module

Built-in, unpluggable fans

Airflow (facing the front panel)

Left-to-right

Management interfaces

1 (RJ45)

CON/AUX interfaces

1 (RJ45)

USB 2.0 interfaces

1

Service interfaces

WAN interfaces: one ADSL-A/M interface and two 3G-HSPA+7 antenna interfaces

LAN interfaces: eight FE electrical interfaces, in which LAN interface FE0 can be used as a WAN interface

Extended slots

Not supported

Operating temperature

0°C to 45°C (32°F to 113°F)

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Operating relative humidity

5% to 95%, noncondensing

Operating altitude

< 5000 m (16404.2 ft.)
