Enclosure   type

Rack-mountable   – 1U

Ports

48 x 10/100/1000 (POE+) + 4 x 1G SFP

Network   management Interface

Ethernet   management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling
Management console port: RJ-45-to-DB9 cable for PC connections

Available   PoE Power

390W

Switching   Capacity

176 Gbps

Maximum   stacking number

9

Stack   Bandwidth

160 Gbps

Forwarding   Performance

77.37 Mpps

FNF   entries

Disabled (IP base license required)

Maximum   VLANs IDs

255

MAC   Address Table Size

32K

CPU

Multicore CPU

RAM

4 G

Flash   Memory

2 G

Number   of AP per switch/stack

50

Number   of wireless clients per switch/stack

1000

Total   number of WLANs per switch

64

Wireless   bandwidth per switch

up to 40 Gbps

Supported   Aironet AP series

3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040

Console   ports

USB (Type-B), Ethernet (RJ-45)

Expansion   Slot(s)

power redundant slot

Accessory   & Rack Moubt Kits

(1)ACC-KIT-T1:   Accessory kit
(2)RACK-KIT-T1: Rack mount kit
(3)4PT-KIT-T1:Extension rails and brackets for four-point mounting

Stacking   module & cable

(1)C3650-STACK-KIT:   Stack Module
(2)STACK-T2-50CM: StackWise-160 stacking cable with a 0.5 m length
(3)STACK-T2-1M: StackWise-160 stacking cable with a 1.0 m length
(4)STACK-T2-3M: StackWise-160 stacking cable with a 3.0 m length

Power   supply

PWR-C2-1025WAC

Power   Device

Power supply – redundant – plug-in module

Power   Redundancy

optional

Voltage   range (Auto)

100V-240V

Power   Consumption of standalone (in Watts)

99.5 (max)

Width

17.5 Inches (44.5 cm)

Depth

17.625 Inches (44.8 cm)

Height

1.73 Inches (4.4 cm)

Shipping   Weight

17.49 Kg

Rack   Mounting Kit

optional

MTBF   in hours

383,760

Compliant   Standards

●IEEE   802.1D Spanning Tree Protoco

●   IEEE 802.1p CoS Prioritization

●   IEEE 802.1Q VLAN

●   IEEE 802.1s

●   IEEE 802.1w

●   IEEE 802.1X

●   IEEE 802.1X-Rev

●IEEE   802.11

●   IEEE 802.1ab (LLDP)

●   IEEE 802.3ad

●   IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports

●   IEEE 802.3 10BASE-T

●   IEEE 802.3u 100BASE-TX

●   IEEE 802.3ab 1000BASE-T

●   IEEE 802.3z 1000BASE-X

●   RMON I and II standards

●   SNMP v1, v2c, and v3

System   software

IOS LAN Base（Upgradable）

EnergyWise   license

ENERGY-MGMT,   ENERGY-MGT-100-K9

Access   Point Licenses

●L-LIC-CT3650-UPG:   Primary upgrade license SKU for Cisco 3650 wireless controller (e-delivery)   ●L-LIC-CTIOS-1A: 1 access point adder license for Cisco IOS Software based   wireless controller (e-delivery)

●L-LIC-CTIOS-1A:   1 access point adder license for Cisco IOS Software based wireless controller   (e-delivery)

●LIC-CTIOS-1A:   1 access point adder license for the Cisco IOS Software based wireless   controller (paper license)

features

●EEM   ● RPS Support ● IP service-level agreements (SLAs) ● Advanced IP unicast   routing protocols

●   Jumbo Frames ● VLANS ●Voice Vlan ●VTPv2 ●CDPv2 ●LLDP

●   802.3ad LACP and PAgP ● PVST/PVST+ ● 802.1W/802.1S ●Port Fast/Uplink Fast   ●Dynamic Trunking Protocol (DTP) ● port CoS Trust and Override

●   Trusted Boundary ● ACL Classification ●ingress Policing ● Auto QoS ● Per VLAN   policies ● 802.1p queues

●   Scheduling ● Priority Queuing ● Configure CoS Priority Queues ●Configure CoS   Priority Queues ● Configure Queue Weights ● Configure Buffers and Thresholds   ●Class & Policy Maps

●   Modify CoS and DSCP Mapping ● Weighted Tail Drop ● IGMPv1,v2,v3 and MLDv1, v2   ● DHCP server

●   DSCP transparency ● HSRP, VRRP, BLGP ● RIPv1, v2 EIGRP, PIM OSPF, OSPFv3,   EIGRPv6, BGPv4, ISISv4

●   VRF-lite ● PIM-SM/DM, PIM sparse-dense mode, SSM ● Flexible Netflow

Advanced   Network security

●Port   security ● DHCP snooping ●Dynamic ARP inspection (DAI) ● IP source guard ●The   Unicast Reverse Path Forwarding (uRPF)

●   Bidirectional data support on a SPAN ● User authentication

●   Private VLAN ●Router and VLAN ACLs ● complete identity and security

●   Multidomain authentication ● MAC address notification

●   IGMP filtering ● Cisco security VLAN ACL

●   Secure Shell (SSH) Protocol, Kerberos, and Simple Network Management Protocol   Version 3 (SNMPv3)

●   Port-based ACLs ● TrustSec SXP ● IEEE 802.1ae

●   TACACS+ and RADIUS authentication ● Cisco standard and extended IP security   router ACLs

●   Bridge protocol data unit (BPDU) Guard

●   Spanning Tree Root Guard (STRG) ● Wireless end-to-end security

Technical   Support and Services

●   Cisco SMARTnet Service ● Cisco Smart Foundation Service

●   Cisco SP Base Service ● Cisco Focused Technical Support Services

Operating   temperature up to 5000 ft (1500 m)

23ºF   to 113ºF (-5ºC to +45ºC)

Operating   temperature up to 10,000 ft (3000 m)

23ºF   to 104ºF (-5ºC to +40ºC)

Short-term   exception at sealevel with single fan failure

23ºF   to 113ºF (-5ºC to +45ºC)

Short-term   exception up to 5000 feet (1500 m)

23ºF   to 122ºF (-5ºC to 50ºC)

Short-term   exception up to 10,000 feet (3000 m)

23ºF   to 113ºF (-5ºC to 45ºC)

Operating   temperature up to 6000 ft (1800 m)

23ºF   to 113ºF (-5ºC to +45ºC)

Operating   temperature up to 10,000 ft (3000 m)

23ºF   to 104ºF (-5ºC to +40ºC)

Operating   temperature up to 13,000 ft (4000m)

23ºF   to 95ºF (-5ºC to 35ºC)

Short-term   exception up to 6,000 feet (1800 m)

23ºF   to 131ºF (-5ºC to +55ºC

Short-term   exception up to 10,000 feet (3000 m)

23ºF   to 122ºF (-5ºC to +50ºC

Short-term   exception up to 13,000 feet (4000 m)

23ºF   to 113ºF (-5ºC to +45ºC)

Short-term   exception at sealevel with single fan failure

23ºF   to 113ºF (-5ºC to +45º)

Storage   environment

-40ºF   to 160ºF (-40ºC to 70ºC)

Operating   altitude

Up   to 16,400 Feet (Up to 5000m)

Storage   altitude

Up   to 16,400 Feet (Up to 5000m)

Operating   relative humidity

5%   to 96% noncondensing

Storage   relative humidity 5

5%   to 96% noncondensing
